Table Of Contents; Models Available - Monogram Advantium ZSB9131NSS Installation Instructions Manual

BEFORE YOU BEGIN
Read these instructions completely and
carefully.
IMPORTANT
-
Save these instructions
for local inspector's use.
IMPORTANT
-
Observe all governing codes
and ordinances.
Note to Installer
•
instructions with the Consumer.
Note to Consumer
•
with your Owner's Manual for future reference.
Skill Level
Installation of this appliance
• -
requires basic mechanical and electrical skills.
Completion Time
•
• Proper installation is the responsibility
of the installer. Product failure due to improper
installation is not covered under the warranty.
See Owner's Manual for warranty information.
IMPORTANT
-
Use this oven only for its
intended purpose. Never use the oven for
warming or heating a room. Prolonged use
of the oven without proper ventilation can be
hazardous.
For personal safety, remove
CAUTION
house fuse or oven circuit
breaker before beginning installation to avoid
severe or fatal shock injury.
For personal safety, the
CAUTION
mounting surface must be
capable of supporting the cabinet load, in addition
to the added weight of the oven and drawer, plus
additional oven loads.
2
Safety Information
- Be sure to leave these
-
Keep these instructions
- 1 Hour.
CONTENTS
Design Information
Models Available .............................................. 2
Product Dimensions and Clearances ............... 3
Tools and Parts Required ................................ 3
Advance Planning ............................................ 3
Installation Preparation
Electrical Requirements ................................... 4
Preparing the Opening (Standard) ................... 5
Preparing the Opening (Flush Mount) .............. 9
Storage Drawer Preparation
Standard ........................................................ 11
Flush .............................................................. 11
Installation Instructions
Step 1, Remove Packaging and Parts ........... 12
Step 2, Slide the Oven into the Cutout .......... 13
Step 3, Install Bottom Trim ............................. 13
Step 4, Install Bottom Trim with Accessory
Drawer .......................................................... 13
Step 5, Install Mounting Screws ..................... 14
Step 6, Finalize Installation ............................ 14

MODELS AVAILABLE

ZSB9131NSS - Stainless Steel
ZSB9132NSS - Stainless Steel
31-7000079 Rev. 0
