- Page 1 BC245300TX Industrial Adjustable Stool For assistance with assembly, contact: Assembly Instructions Southern Enterprises Inc. Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#: Page 1...
- Page 2 Industrial Adjustable Stool Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Industrial Adjustable Stool Assembly Instructions Connect Legs (E) to Adjustable Leveler (D) and Bottom Metal Ring (C) with Bolt (1,2), Spring Washer (3) and Flat Washer (4, 5). Tighten Bolt (1,2)) with Allen Wrench (6). Figure 1 Connect the 4th Leg (E) to Adjustable Leveler (D) and Bottom Metal Ring (C) with Bolt (1,2), Spring Washer (3) and Flat Washer (4,5).
- Page 4 Connect Footrest Ring (B) to pre-assembled unit from Figure 2 with Bolt (2), Spring Washer (3) and Washer (5). Tighten Bolt (2) with Allen Wrench (6). Figure 3 Connect pre-assembled unit from Figure 3 to Seat (A) with Bolt (2), Spring Washer (3) and Flat Washer (4) Tighten Bolt (2) with Allen Wrench (6).
- Page 5 Turn over the Barstool Now your Industrial Adjustable Stool is ready to use! Figure 5 To swivel Seat (A) can adjust its height, If the Barstool is not level, please adjust the Leg’s leveler by hand as shown. Figure 6 Page 4...
-
Page 6: Parts Replacement Form
Parts Replacement Form Page11 Page 4 Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
