SOUTHERN ENTERPRISES INC.
NOTE.... This product has been engineered for
easy assembly and constructed for durability.
Please take time to read and follow assembly instructions.
No.
Description
Left Side Frame
A
B
Right Side Frame
C
Brace
D
Front Apron
E
Back Apron
F
Bottom Panel
G
Seat Panel
H
Back
Assembly Instruction
PARTS AND HARDWARE LIST
Q'ty
Sketch
1
1
1
1
1
1
1
1
STYLE NO.:
BC921900TX- Antique Red Storage Bench w/o cushion
BC931900TX- Brown Mahogany Storage Bench w/o cushion
No.
Description
1
Long Blot(1/4"*2")
2
Short Bolt(1/4"*1")
3
Wood Dowle
4
Hinge
Long Wood
5
Screw(8#*3/4")
Short Wood
6
Screw(3*14*D6)
7
Washer
8
Plastic Pad
9
Anti-Slip Hinge
10
Wood Plug
11
Allen Wrench
1
Q'ty
Sketch
12
2
2
2
1
12
1
1
1
14
1
Page 1 of 5
