- Page 1 BC304400TX-COUNTRY OAK / BC304900TX-BLACK 3-Drawre Country Bench For assistance with assembly contact: Southern Enterprises Inc. Assembly Instruction Customer Service 1-800-633-5096 service@seidal.com www.seidal.com PO#13112 250lb Max Seat Load.
- Page 2 BC304400TX-COUNTRY OAK / BC304900TX-BLACK 3-Drawer Country Bench Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Screws shown actual size. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw.
- Page 3 Quantity Quantity Quantity Of 12 Of 32 Of 12 Bolt 1/4”x 2-3/4” Barrel Nut 1/4” Dowel 5/16” x1-1/4” Quantity Quantity Quantity Of 3 Of 6 Of18 Screw ∮ 5/32”x2” Plastic Drawer Support Screw ∮ 1/8”x1/2” Quantity Quantity Quantity Of 36 Of 3 Of 3 Screw ∮...
- Page 4 BC304400TX-COUNTRY OAK / BC304900TX-BLACK 3-Drawer Country Bench Assembly Instruction Step 1: Attach wood slide (L) to bottom panel (D) by using screw (4) and dowel (3) as shown. Step 2: Attach plastic drawer stopper (10), right plastic support (8) and left plastic...
- Page 5 Step 3: Insert dowel (3) to side apron (G), back panel (E) and front panel (F) as shown. Step 4: Insert dowel (3) into bottom panel (D) and attach drawer frame to bottom panel (D) by using screw (7) as shown.
- Page 6 Step 5: Insert dowel (3) to left side panel (A) and right side panel (B). Attach side panels to the frame by using bolt (1) and barrel nut (2) as shown. Step 6: Attach plastic drawer support (5) to drawer rear panel (J) by using screw (6) as shown.
- Page 7 Step 7: Insert drawers to bench. Step 8: Insert wood plug (11) to side panels as shown.
- Page 8 Parts Replacement Form Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
