BC946100TX
For assistance with assembly, contact:
Southern Enterprises Inc.
Artisan Storage Bench
customer service 1-800-633-5096
service@seidal.com
www.seidal.com
Assembly Instructions
PO#:

Advertisement

loading
Need help?

Need help?

Do you have a question about the Artisan BC946100TX and is the answer not in the manual?

Questions and answers

Related Manuals for SEI Artisan BC946100TX

Summary of Contents for SEI Artisan BC946100TX

  • Page 1 BC946100TX For assistance with assembly, contact: Southern Enterprises Inc. Artisan Storage Bench customer service 1-800-633-5096 service@seidal.com www.seidal.com Assembly Instructions PO#:...
  • Page 2 Artisan Storage Bench Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing.
  • Page 3 Quantity Quantity Quantity of 1 of 1 of 1 drawer right side panel drawer back panel drawer bottom panel Quantity of 1 seat cushion Quantity Quantity Quantity of 10 of 32 of 32 cam lock wood dowel ø8*30mm cam bolt Quantity Quantity Quantity...
  • Page 4 Quantity Quantity Quantity of 8 of 1 of 2 bolt for handle Flat head screw ø1/8” x 5/8” handle ø5/32 x 1/2” Quantity of 10 sticker cover Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth. call customer service at 1-800-633-5096.
  • Page 5 Artisan Storage Bench Assembly Instructions Connect apron back panel (B) to apron side panels (C) with bolts (6) and wood dowels (1). Tighten bolts (6) with phillips screwdriver. Figure 1 Connect assembled unit to top panel (A) with bolts (7) and wood dowels (1). Tighten bolts (7) with phillips screwdriver.
  • Page 6 Artisan Storage Bench Assembly Instructions Insert cam locks (3) into holes on drawer back panel (N). Screw cam bolts (2) into holes on drawer left side panel (L) and drawer right side panel (M). Attach drawer left side panel (L) and drawer right side panel (M) to drawer back panel (N) by inserting cam bolts (2) into corresponding holes until they meet.
  • Page 7 Artisan Storage Bench Assembly Instructions Insert cam locks (3) into holes on assembled unit. Screw cam bolts (2) into holes on drawer front panel (K). Attach assembled unit to drawer front panel (K) by inserting cam bolts (2) into corresponding holes until they meet. Tighten by rotating cam locks (3) clockwise with phillips screwdriver.
  • Page 8 Artisan Storage Bench Assembly Instructions Insert cam locks (3) into holes on underside of fixed shelf (F). Screw cam bolts (2) into holes on front panel (G). Attach front panel (G) to fixed shelf (F) by inserting cam bolts (2) into corresponding holes until front panel (G) and fixed shelf (F) meet.
  • Page 9 Artisan Storage Bench Assembly Instructions Repeat the steps on figure 8 to attach left side frame (E) to the assembled unit. Figure 9 Insert cam locks (3) into holes on assembled unit. Screw cam bolts (2) into holes on underside of top panel (A). Attach top panel to assembled unit by inserting wood dowels (1) and cam bolts (2) into corresponding holes until they meet.
  • Page 10 Artisan Storage Bench Assembly Instructions Connect back panel (J) to assembled unit on as shown using screws (5). Tighten screws (5) with phillip screwdriver. Figure 11 Open the top panel as shown. Attach spring hinge-left (8) and spring hinge-right (9) to the top panel and bench base with screws (10).
  • Page 11 Artisan Storage Bench Assembly Instructions Screw drawer bolts (4) into holes on side leg as shown. Attach assembled drawer box into assembled unit on as shown. Make sure the bolts (4) holds the drawer box stably. Figure 13 Place seat cushion (P) on top panel as shown.
  • Page 12 Artisan Storage Bench Assembly Instructions Now your new Artisan storage bench is ready to use. Figure 15...

  • Page 13: Parts Replacement Form

    Parts Replacement Form Page11 Page 4 Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
