- Page 1 BC107000TX ADJUSTABLE BARSTOOL - GARRATT For assistance with assembly contact: Southern Enterprises, Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com wwww.seidal.com...
-
Page 2: Leg Extensions
ADJUSTABLE BARSTOOL - GARRATT Parts List Please review all parts and hardware before disposing of any packaging. Call Customer Service if missing hardware. Do not return to store/retailer. Using a screw that is too long will cause damage. Before beginning assembly, separate each type of screw. - Page 3 2pcs 6pcs Φ1/4”X 7/8”L Bolts Φ1/4”X 1-1/4”L Bolts 11pcs 11pcs Washers Lock Washers 4pcs Foot-Inserts Allen Wrench Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth. Call Customer Service at 1-800-633-5096 Avoid rubbing or scratching the Do not return product to store, please call surface with rough or abrasive objects.
-
Page 4: Adjustable Barstool - Garratt
ADJUSTABLE BARSTOOL - GARRATT Assembly Instructions 1. Assemble leg frames (D, E) by inserting the leg Figure 1 frame (D) (with the center slot on bottom of crossbar), on top of the leg frame (E) (with the center slot on top of the crossbar), as shown. 2. - Page 5 1. Place seatframe assembly upside down and Figure 4.1 fasten the backrest (A) to frame of seat cushion (B) as shown using one bolt (H), one lock washer (L) and one washer (K) for the middle hole, only tighten halfway. Then insert two bolts(I) into the right and left holes, with one lock washer (L) and one washer (K), as shown in the enlarged diagram, using Allen wrench (N), only tighten...
- Page 6 You now have two options: Figure 5(a) (a) If you choose a 24" seat height : 1. Insert a foot-insert (M) onto each leg (D, E). 2. Place barstool upright on the floor.
- Page 7 (b) If you choose a 29" seat height : Figure 5(b) 1. You need to insert four leg extensions (G) into leg frames (D, E) using four bolts (H) and tighten securely. 2. Place barstool upright on the floor. ** Weight restriction: 250 lbs. ** We recommend that you save the Allen wrench (M) and periodically tighten all bolts.
-
Page 8: Parts Replacement Form
Parts Replacement Form Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
