Summary of Contents for SEI BC401700TX
- Page 1 BC401700TX Loring Entryway Storage Bench For assistance with assembly contact: Southern Enterprises, Inc. Customer Service 1-800-633-5096 Assembly Instructions service@seidal.com www.seidal.com PO#:...
- Page 2 Loring Entryway Storage Bench Parts List Please check packaging for all parts and hardware before discarding. Unpack and lay parts on clean, padded surface like carpet or blanket. Check that you have all parts indicated. Call customer service if hardware is missing. Before beginning assembly, carefully study the diagrams below and sort your hardware according to the pictures.
- Page 3 Quantity of 1 Cushion Quantity Quantity Quantity of 29 of 29 of 18 Wood Dowel Ø5/16”x1-1/2”L Cam Lock Cam Bolt Quantity Quantity Quantity of 5 of 22 of 12 Adhesive Pad Screw Ø1/8”x1/2”L Screw Ø5/32”x1”L Care and Cleaning Instructions: For replacement parts or questions, please Before using, wipe with a clean, dry cloth.
- Page 4 LORING ENTRYWAY STORAGE BENCH Assembly Instructions ( 1 ) ( 2 ) Insert cam locks (2) into holes on back cross Panel (F). Screw cam bolts (1) into holes on bottom “Please do not over tighten cam bolts, panel (E). please stop when you feel them tighten"...
- Page 5 Insert cam locks (2) into holes on bottom panel (E), rear cross panel (F), and front cross panel (G). Screw cam bolts (1) into holes on side panels (B) and (C). Attach side panels (B) and (C) to bottom panel (E), rear cross panel (F), and front cross panel (G) by inserting cam bolts (1) and wood dowels (3) into corresponding holes until panels meet.
- Page 6 Insert cam locks (2) into holes on assembled unit as shown. Screw cam bolts (1) into holes on top panel (A). Attach top panel (A) to assembled unit by inserting wood dowels (3), cam bolts (1), and screws (4) into corresponding holes until panels meet.
- Page 7 Attach the wicker bottoms (L) to wicker frames (K). Figure 7 Place wicker baskets into the assembled unit. Figure 8...
- Page 8 Place the cushion (M) onto top panel (A). Figure 9 Now your Loring entryway storage bench is ready to use. Figure 10...
-
Page 9: Parts Replacement Form
Parts Replacement Form Page11 Page 4 Customer Information Name Address City/State/Zip Code Phone Number Please indicate where you purchased this item: Store/Website/Catalog Please indicate color/size/style number: Style No Parts Letter Parts Description Quantity Needed Please immediately examine this product carefully. Any request for missing parts or damage replacement must be received within 90 days of your receipt of the product.
