User - CP Electronics UNLCDHS Programming Manual

UNLCDHS Programming – User
Basic Parameters for all models including '-PRM', '-PRM-2CH', '-DD/SR' and '-AD' and their variants
Parameter
Select Scene
Select Scene
(pre V3 models)
Scene Up
Scene Down
Set Scene Level
(V3)
Raise
Lower
Manual Override
On
Manual Override
Off
Manual Override
Cancel
Note: Certain parameter functions are only available in specific versions of the detectors and these are indicated under the affected parameter headings
within the brackets e.g. LUX Learn Level (V3).
30
Default Range / Option
1 1 – 8
6 1 – 6
– –
– –
0 0 – 255
– –
– –
– –
– –
– –
The preset dimming levels are as follows (does not operate the relay outputs):
Scene 1 – Maintained illuminance
Scene 2 – 100%
Scene 3 – 75%
Scene 4 – 50%
Scene 5 – 25%
Scene 6 – 15%
Scene 7 – 10%
Scene 8 – 0% (min)
The preset dimming levels are as follows:
Scene 1 – 0% (minimum)
Scene 2 – 10%
Scene 3 – 25%
Scene 4 – 50%
Scene 5 – 75%
Scene 6 – 100%
Changes the scene from 1 up to 8. (1–6 for pre V3 models)
Changes the scene from 8 down to 1. (6 down to 1 for pre V3 models)
Changes a particular scene's preset level. Select the scene first using Select Scene
and then send Set Scene Level.
255 = 100%
191 = 75%
128 = 50%
64 = 25%
26 = 10%
0 = 0% (min)
Increases light level. Reverts to programmed light levels when absence detected.
Decreases light level. Reverts to programmed light levels when absence detected.
Turns lights on and reverts to automatic operation after the period set by Manual
Timeout in the Detector Params menu.
Turns lights off and reverts to automatic operation after the period set by Manual
Timeout in the Detector Params menu.
Cancels the manual on and off overrides, returning the detector to normal
operation.
Description
