CP Electronics MWS5 Product Manual

MWS5
Miniature Ceiling Mounted Microwave Presence Detector
Section Contents
1 Description and operation
2 Dimensions
3 Wiring
4 Setup
5 Programming
6 Detection pattern diagrams
7 Fault finding
8
Specification
9 Part numbers
The MWS5 series of miniature microwave presence
detectors provide automatic control of lighting loads
with optional manual control. The unit comes
complete with a selection of fixing clips, allowing
unobtrusive flush mounting of the sensor head into
ceiling tiles or on to solid surfaces. It has been
designed so that it can be used for ceiling mounted
or wall mounted applications. As microwave
radiation penetrates plastic and glass, this unit has
been specifically designed to be mounted inside a
luminaire. If you wish to use this type of control
outside a luminaire housing, please use the
-SA‖ (Standalone) version.
Feature
Up to 8m microwave sensing
3 mounting options
Lux sensor
Absence detection
Presence detection
Infrared remote setting
Infrared user handset
Push button adjustment*
Relay output
Dimming output
Absence switch input
Up/down switch input
*for lux, time and sensitivity
Product Guide
1. Description and Operation
Three models are available: non-dimming MWS5,
direct dim -DD and analogue dim -AD, all of which
will switch incandescent, fluorescent and compact
fluorescent lighting. The direct dim (DD) variant
controls DSI or DALI digital dimming ballasts whilst
the analogue dim (AD) variant controls 1-10V
analogue dimming ballasts.
The unit detects movement using a microwave
sensor and turns the load on. When an area is no
longer occupied the load will switch off after an
adjustable time out period has elapsed.
MWS5
(Non-dimming)










MWS5-DD MWS5-AD
Direct Dim Analogue Dim












