Configuration - CP Electronics UNLCDHS Programming Manual

UNLCDHS Programming – Configuration
Advance Parameters for all models including '-PRM' and '-PRM-2CH', '-DD/SR' and '-AD'
Parameter
Channel Mode
(not applicable to
V2 PRM models)
Switch Mode
(PRM models)
Switch Mode
(PRM-2Ch models)
Switch Mode
(dimming control
models DD, AD
etc..)
Factory Reset
Soft Reset
LUX Cal Value (V3)
LUX Cal Factor
(V3)
IR Enabled (V3)
Note: Certain parameter functions are only available in specific versions of the detectors and these are indicated under the affected parameter headings
within the brackets e.g. LUX Learn Level (V3).
24
Default Range / Option
Switch Switch only
and dim
Switch and dim
together
together
Switch and dim
seperate
Long Press Long Press Off,
Off, Short Press On
Short Press Short Press Off,
On Short Press On
Long Press
Off,
Short Press
On
2 position
switch
together
– –
– –
0 0 – 999
0 0 – 255
Yes Yes / No
Submenu to configure dimming controls.
Switch only
Choose this option if the dimming channel is not required (for example with
single channel devices)
Usually used for absence detection, as in this mode the dimming channel is not
used.
Switch and dim together (not applicable to PRM models)
Choose this when the channel 1 output is also used to power dimming
luminaires on channel 2.
If both channels are powered by an external source there is a 1 second delay
between channel 1 luminaires being switched and dimming commands being
sent on channel 2. To avoid this delay use the Switch and dim separate option.
Switch and dim separate (not applicable to PRM models)
Choose this option on unit when channel 1 is switched using the relay output
and channel 2 is powered from an external 230V power source so that both
channels work independently.
Submenu to configure switches.
Long Press Off, Short Press On (1 position switch together in pre V3 models)
A single momentary switch where you must press for 3 seconds to switch the
load OFF and a short press ON.
Short Press Off, Short Press On (2 position switch together in pre V3 models)
A single momentary switch where a short press switches the load ON and
another short press to switch OFF.
Long Press Off, Short Press On & 1 position switch together
A single position retractive switch controls both channels together.
Long Press Off, Short Press On & 1 position switch separately
Two single position retractive switches, controlling the channels separately
Short Press Off, Short Press On & 2 position switch together
A single position retractive switch controls both channels together.
Short Press Off, Short Press On & 2 position switch separately
Two single position retractive switches, controlling the channels separately
2 position switch together:
A single centre biased retractive switch will control both channels together.
2 position switch separately:
A single centre biased retractive switch will control only the dimming channel.
1 position switch together:
A single position momentary switch will control both channels together.
1 position switch separately:
Two single position momentary switch will control the channels separately.
Clears any programmed settings and returns the device to its default set-up.
Reboots the device, but retains all current settings. Must leave value at zero.
Enter the current reading of a LUX meter to calibrate the scale of the photocell in the
detector. Must reset and send to 0 before applying a new setting.
Reads back the effective scaling factor calculated from the photocell LUX Learn
reading and LUX Cal Value.
Set to No to prevent the device from receiving commands from the handset. The
device's LED will flash several times if you try to send a command when in this state.
Set to Yes to re enable programming.
Description
