CP Electronics UNLCDHS Programming Manual page 29

UNLCDHS Programming – Output Ch. 2
Advance Parameters for Dimming models '-DD/SR' and '-AD' and their variants only
Parameter Default
Off Value 0
Max Value 99
Min Value 1
Memorise (V2) No
Switch memorise
(V3)
Burn-in Hours 0
Speed (On) 40
Speed (Setup)
5
Set Seconds 120
EBDHS High Bay
–
models only
Note: Certain parameter functions are only available in specific versions of the detectors and these are indicated under the affected parameter headings
within the brackets e.g. LUX Learn Level (V3).
Range / Option
0 – 99 Dimmed output level when lights manually switched off or after detector times out.
0 – 99 Maximum dimming output level.
0 – 99 Minimum dimming output level.
Yes / No If set to Yes, the last manually set output level will be memorised and used as the
switch ON level.
1 – 999 hours Determines how long the output will be at 100% so that new lamps burn-in. The
(0 = disabled) burn-in time is not affected by power supply interruptions.
0 – 99 seconds Determines the dimming response speed during the set up time upon power ON.
Measured in 0.1 sec intervals.
If set to "0" will disable dimming for Set Seconds below, used if fittings are required to
warm up before dimming.
0 – 99 Determines how long the dimming response set-up period lasts upon power-up or
on setting change. This enables a faster set up time.
0 – 999 seconds Sets the dimming response speed after the setup time has finished.
Measured in 0.1 sec intervals (i.e. a value of 40 means 4 seconds).
– Submenu for configuring high-bay detectors.
PIR 1-5
Switches each of the 5 sensors within the detector on or off individually.
Default = On, Option = On / Off
Verify Mode
Requires at least 2 sensors within the detector to detect movement before
triggering the lights.
Default = Yes, Option = Yes / No
Description
