UNLCDHS Programming – Output Ch. 1
Advance Parameters for all models including '-PRM', '-PRM-2CH', '-DD/SR' and '-AD'
Parameter Default
Detection Mode Pres
Timeout 20 minutes
Abs Recovery 10
(secs) (V3)
Relay Status (V3) Off
(Not for '-2CH'
models)
LUX On Level 999
LUX Off Level 999
LUX On Time 0
(V3)
LUX Off Time 0
(V3)
On Delay
0
EBDHS High Bay –
models only
Note: Certain parameter functions are only available in specific versions of the detectors and these are indicated under the affected parameter headings
within the brackets e.g. LUX Learn Level (V3).
Range / Option
Pres (Presence) / Select Pres to turn lights on when movement is detected and off when movement
Abs (Absence) ceases. Select Abs to turn lights off when movement ceases, but the lights must be
manually turned on by a switch or handset first.
0 – 99 minutes How long the lights stay on for after movement has stopped. (Channel 1). Select 0 for
a 10 second delay (use for commissioning only).
0 – 99 seconds Sets a period for a detector in Absence mode to operate in Presence mode after lights
(applies to both channels are turned off. This enables a person to use movement to re trigger lights which have
in '-2CH' models) switched off while they are still in the room. If Abs Recovery (secs) is set to a non-zero
value you should also set Inhibit to 0 to detect any occupancy immediately.
On / Off Use with the Readback function to see whether the detector switch relay is currently
in an On or Off state.
1 – 9 (V2) Sets a minimum ambient light level below which lights are turned on by movement.
1 – 950, 999=disabled The LUX Off Level value must always be greater than the LUX On Level value.
(V3)
1 – 9 (V2) Sets a maximum ambient light level above which lights cannot be turned on by
movement.
1 – 950, 999=disabled
(V3) The LUX Off Level value must always be greater than the LUX On Level value.
0 – 99 minutes When the ambient light falls below LUX On Level, the time to wait before switching
on the lights. If at any time during the timed delay the LUX change reverses then the
process is cancelled. Minimum time of around 15 seconds is set for a value of 0.
If you try to turn lights on using a switch or handset, the lights will go on regardless of
ambient light level. However, if there is sufficient ambient light, they will turn off again
after LUX Off Time.
0 – 99 minutes When the ambient light rises above LUX Off Level, the time to wait before switching
off the lights. If at any time during the timed delay the LUX change reverses then the
process is cancelled. Minimum time of around 15 seconds is set for a value of 0.
0 – 99 minutes Enables Channel 1 to switch on a number of minutes after Channel 2.
For example if a detector is controlling lighting on Channel 2 and air conditioning
on Channel 1, when an occupant is detected, the lighting turns on immediately, but
the air conditioning turns on after 5 minutes. If the area is vacated and the detector
times out before the delay, then the air conditioning would never go on.
– Submenu for configuring high-bay detectors.
PIR 1–5
Switches each of the 5 sensors within the detector on or off individually.
Default = On, Option = On / Off
Verify Mode
Requires at least 2 sensors within the detector to detect movement before
triggering the lights.
Default = Yes, Option = Yes / No
Description
