UHS5 Programming
For Dimming models including '-DD/SR' and '-AD' models
For most basic programming operations the UHS5 handset can be used and the following procedures are based on using this device.
Point the handset at the sensor and send the required programming commands to the unit as shown below. Valid commands
will be indicated by a red LED flash. See page 1 for details of other LED responses.
Note: other functions on the UHS5 which are not shown below are not applicable to this product.
Parameter Default
Name Value
On / Raise
Off / Lower
Walk test
Off
Time Out
(Time 20 mins
adjustment)
LUX on level
(Switch level 9
on)
6
Light Level
9 (V3)
LUX off level
(Switch level
9
off)
DALI
Load type
D_ON (V3)
Sensitivity 9
Defaults
Burn-in
0
(Hours)
Presence /
Presence
Absence
Shift
10
Number of shift
0 1
SHIFT 1 SHIFT 2 SHIFT 1 SHIFT 2 SHIFT 1
Cancel
On Raise
overide on
Cancel
Off Lower
overide off
On Off
1, 10 & 20 5, 15 & 30 10 seconds
minutes minutes (5/1 button)
2, 5 & 7 4, 6 & 9
2, 5 & 7
2, 5 & 7 4, 6 & 9
2 – Dali
7 – DSI
1, 5 & 9 3, 6 & 8
0 50 100
Presence Absence
presses
2 3
UHS5 Handset
Graphics
SHIFT 2 SHIFT 1 SHIFT 2
4, 6 & 9
2 – D_ON
D
Description
Turn lights on or to raise lights.
Turn lights off or to lower lights.
When set to On this causes a red LED
to flash on the sensor when it detects
movement. Use this feature to check for
adequate sensitivity levels.
Once the detector is turned on, this
value sets how long the lights will stay
on once movement has ceased.
LUX level setting to prevent the
luminaires from being switched on if
the light level is sufficient (adjustable
between 2 and 7). The luminaires will
always be switched on at level 9.
Sets a target preset light level between
2 and 7 to be maintained by the lighting
system. 9 = disabled.
LUX level setting switches the luminaires
off if the light level goes above the
setting (adjustable between 2 and 7).
Level 9 will always keep the lights on.
This setting can be used for "window
row switching".
Note: the LUX Off Level value must always
be greater than the LUX On Level value.
Sets the ballast control protocol to be
used by the output channel.
For both ON and OFF, sensitivity level for
detecting movement.
1 = low sensitivity
9 = high sensitivity
Returns the unit to the default settings.
Determines how long the output will
be at 100% so that lamps 'burn-in'. The
'burn-in' time is not affected by power
supply interruptions.
Presence mode allows the output to
turn on when movement is detected
and off when movement ceases.
Absence mode allows the output to turn
off when movement ceases, but must be
manually turned on first.
Use this button to select the settings in
red and blue signified by the 'Shift 1' and
'Shift 2' LEDs
