3 Install the exterior keypad
A
What is the diameter of the hole in the door?
Diameter is 2-1/8"
(54 mm)
2-1/8"
54 mm
"D" is required for installation.
Install "D" on "E".
E
D
B
Locate screws for step 3C and keep them within reach.
P
4 Install the interior assembly
A
Remove battery cover and battery pack from interior assembly.
a
Make sure turnpiece is in
the vertical position.
c
Make sure
turnpiece shaft is
rotated as shown.
K
5 Install the batteries and perform the door handing process
This step will teach your lock the orientation of your door and is crucial to lock operation.
A
Install 4 AA batteries in battery pack.
T
Ensure correct polarity.
For best results, use
new, non-rechargeable
Alkaline batteries only.
Diameter is 1-1/2"
(38 mm)
or
1-1/2"
38 mm
"D" is not needed for
installation. Discard "D".
D
b
L
d
J
Do not install
until step 5.
K
B
Press and HOLD the Lock button
while installing battery pack.
Hold button until the latch bolt
starts moving on its own.
J
C
Install exterior keypad and mounting plate.
a
Cable goes
underneath latch.
c
Keep parallel to
edge of door.
P (2x)
Tighten
screws evenly.
B
Install interior assembly onto mounting plate.
a
K
K
Ensure tight cable
connection.
c
batteries
C
b
assembly during
mounting plate
installation.
E
d
P
b
align
Lay excess cable flat inside the
bottom of the interior housing.
d
Q
(2x)
Did the latch bolt retract and extend on its own
when the battery pack was installed?
YES
or
Door handing process
was successful! Proceed
to next step after latch
bolt stops moving.
Support exterior
F
Route cable through
center hole, then push
cable into bottom hole.
H
Insert key and
test latch. If latch
does not extend or
retract smoothly,
adjust screws (P).
Remove key when
finished and make
sure the latch bolt
is fully extended.
Note: Latch
bolt will only
retract half way.
NO
Remove battery pack,
wait 15 seconds, then
attempt the process again.
