Summary of Contents for Minebea Intec Puro EF-LLP1500-3d

  • Page 1 Presented By Dallas Ft Worth Austin Houston NicolScales.com 800.225.8181 Contact Us Nicol Scales & Measurement is an ISO Accredited Calibration Company that has provided calibration, repair and sales of all types of weighing and measurement products since 1931.
  • Page 2 Operating Instructions Floor platform Puro® 98628-000-65 Edition 1.0.1 6/22/2020 Minebea Intec Bovenden GmbH & Co. KG, Leinetal 2, 37120 Bovenden, Germany Phone: +49.551.309.83.0 Fax: +49.551.309.83.190...
  • Page 3 Any information in this document is subject to change without notice and does not represent a commitment on the part of Minebea Intec unless legally prescribed. This product should only be operated/installed by trained and qualified personnel. In correspondence concerning this product, the type, name, and release number/serial number as well as all license numbers relating to the product have to be cited.
  • Page 4: Table Of Contents

    Connection...................................8 3.2.1 Connecting the platform..........................8 Maintenance/repairs/cleaning......................10 Repairs..................................10 Cleaning ..................................10 4.2.1 Instructions for cleaning ..........................10 4.2.2 Cleaning agents.............................. 10 Waste disposal policy .......................... 11 Technical data .............................12 Specification ................................12 Accessories .................................13 Dimensions ................................14 Minebea Intec EN-1...
  • Page 5: Introduction

    WARNING indicates that death or severe, irreversible injury may occur if appropriate safety measures are not observed. Take the corresponding safety precautions. CAUTION Warning of personal injury. CAUTION indicates that minor, reversible injury may occur if appropriate safety measures are not observed. Take the corresponding safety precautions. EN-2 Minebea Intec...
  • Page 6 Warning of damage to property and/or the environment. NOTICE indicates that damage to property and/or the environment may occur if appropriate safety measures are not observed. Take the corresponding safety precautions. Note: User tips, useful information, and notes. Minebea Intec EN-3...
  • Page 7: Safety Instructions

    If there are grounds for rejection of the goods, a claim must be filed with the carrier immediately. A Minebea Intec sales or service organization must also be notified. Visit our website http://www.puroscales.com or contact your dealer.
  • Page 8: Failure And Excessive Stresses

    Do not unnecessarily subject the device to extreme temperatures, corrosive chemical vapors, moisture, shocks, and vibrations. Extreme electromagnetic influences can affect the display value. Once the disturbance has ceased, the product can be used again as intended. Minebea Intec EN-5...
  • Page 9: Device Installation

    The following applies for devices from a platform size of 60 x 80 cm: Wear protective clothing (safety shoes and, if necessary, gloves) When lifting or transporting the weighing platform, always lift it by its longest sides. EN-6 Minebea Intec...
  • Page 10: Checking The Equipment Supplied

    The weight of the platform must be spread equally across the adjustable feet. Adjust the adjustable feet: Retract the adjustable feet (clockwise) in order to lift the scale. Extend the adjustable feet (counter-clockwise) in order to lower the scale. Minebea Intec EN-7...
  • Page 11: Connection

    8. Secure the wires of the load cell cable into the terminals; when doing so, pay attention to the pin assignments and the color coding of the connection cable for the platform/load cell. DGND Ground Signal- Signal+ EN-8 Minebea Intec...
  • Page 12 EF-LLS1500-3d black green white n.a. n.a. blank EF-NNS1500-3d black green white n.a. n.a. blank EF-NNS3000-3d black green white n.a. n.a. blank EF-RRS1500-3d black green white n.a. n.a. blank EF-RRS3000-3d black green white n.a. n.a. blank Minebea Intec EN-9...
  • Page 13: Maintenance/Repairs/Cleaning

    Defective or damaged cables or screw connections must be replaced as a complete unit. WARNING Improper repairs can pose considerable risks to the user. Only have repairs carried out by Minebea Intec qualified dealers using original spare parts. Cleaning 4.2.1 Instructions for cleaning The device must be cleaned of contaminants on a regular basis.
  • Page 14: Waste Disposal Policy

    Before disposing of or scrapping the product, any batteries should be removed and taken to a suitable collection point. Please see our T&Cs for further information. We reserve the right not to accept products that have been contaminated with hazardous substances (ABC contamination) for repair. Minebea Intec EN-11...
  • Page 15: Technical Data

    Net weight (kg) Shipping dimensions in 1,080 x 1,080 x 225 mm (W x D x H) 1,330 x 1,330 x 255 1,330 x 1,330 x 255 1,580 x 1,580 x 255 1,580 x 1,580 x 255 EN-12 Minebea Intec...
  • Page 16: Accessories

    1,000 x 1,000 mm Ramp for ground, stainless steel, for platform di- YP-RFS2 mensions 1,250 x 1,250 mm Ramp for ground, stainless steel, for platform di- mensions 1,500 x 1,500 mm Stand: Stand, ground, stainless steel, height 1,100 mm YP-CFS1 Minebea Intec EN-13...
  • Page 17: Dimensions

    Floor platform Puro® 6 Technical data Dimensions EF-LLP-1500 All dimensions in mm EF-LLS-1500 All dimensions in mm EN-14 Minebea Intec...
  • Page 18 6 Technical data Floor platform Puro® EF-NNP-1500/3000 All dimensions in mm EF-NNS-1500/3000 All dimensions in mm Minebea Intec EN-15...
  • Page 19 Floor platform Puro® 6 Technical data EF-RRP-1500/3000 All dimensions in mm EF-RRS-1500/3000 All dimensions in mm EN-16 Minebea Intec...
  • Page 20 Published by Minebea Intec Bovenden GmbH & Co. KG | Leinetal 2 | 37120 Bovenden, Germany Phone: +49.551.309.83.0 | Email: info@minebea-intec.com www.minebea-intec.com...
