5 Configuring the Governor with the Hand Held Programmer
The parameters contained in the DISPLAY list and numbered 2000 through
3999 are measuring and display values that are not subject to alteration.
Note
ENGINE SAVE
STOP DATA
These keys placed to the left of the control panel (background blue) have not been
allocated any standard functions.

5.2.2 The Second Functions

2nd
With this key, the second or special functions can be invoked. After pressing the
key, an "S" is displayed to the right of the bottom line, and the Hand Held Programmer
will be waiting for the next key to be entered (like a pocket calculator). If inadvertently
pressed, correction is possible by pressing the [2nd] key once more, which will also
make the "S" disappear.
ERRORS
PID
PARAM DISPLAY
The second functions allocated to these keys are jumps to the most relevant parameter
groups. Their significations are:
[PID]
[ERRORS]
[SPEED]
[DROOP]
The following keys open a way to moving through the lists very fast. By pressing the
[2nd] key and then the specified key the following jump functions are performed:
Jump to the first parameter of the currently selected list
BEGIN LIST
ON/OFF
END LIST
Jump to the last parameter of the currently selected list
NUMBER
NEXT
Jump to the first parameter of the next parameter group
LAST
Jump to the first parameter of the previous parameter group
The increment for the last two keys is 100.
Example:
24
GET
DATA
SPEED DROOP
FUNCT CURVES
Jump to the parameters for PID adjustment
Jump to the parameters for error display
Jump to the parameters for speed adjustment
Jump to the parameters for droop adjustment.
Programmer PG 02
