The following overview table shows where the individual parameters are to find.
A detailed parameter list, with which each individual parameter is described, is at the end
of the respective manual with the appropriate software description.
Parameters
No. Designation
1 Number of Teeth,
Speed
100 Stability,
Droop
200 Ramp,
Start
300 Actuator Travel
400 CAN
500 Oil Pressure, Boost
Pressure, Temperature
600 Excitation Control
700 Limitations
800 Switch Functions,
Digital Outputs
900 Setpoint Adjusters,
Sensors
1000 Error Handling
1100
1200 Generator
1350 Locomotive
1500 Analogue Inputs
1600 PWM-Outputs
Analogue Outputs
1700 Positioner
1800 Status
1900 Servo Loop,
Feedback
Programmer PG 02
Measurements
No. Designation
2000 Speed Pickup,
Speed
2100 Stability,
Droop
2200
2300 Actuator Travel
2400 CAN
2500
2600 Excitation Control
2700 Limitations
2800 Switch Functions,
Digital Outputs
2900 Setpoint Adjusters
Sensors
3000 Current Errors
3100 Error Memroy
3200
3350 Locomotive
3500 PWM-Inputs,
Analogue Inputs
3600
3700
3800 Status
3900 Servo Circuit,
Feedback
Functions
No. Designation
4000 Speed Pickup,
Speed
4100 Stability Map,
Droop
4200 Ramp
4300
4400 CAN
4500 Oil Pressure, Boost
Pressure, Temperatuer
4600 Excitation Control
4700 Limitations
4800 Digital Inputs,
Digital Outputs
4900 Setpoint Adjusters,
Sensors
5000 Error Handling
5100 Error Handling
5200 Generator
5250 Marine
5350 Locomotive
5500 Channel Type
5600 Analogue Outputs
5700 Positioner
5800
5900 Servo Loop,
Feedback
Table 1: Parameter Overview
2 General
Curves
No. Designation
6000
6100 Stability Map
6200 Stability Map
(Correction Values)
6300
6400 Boost Pressure dependent
Fuel and Load Limitation
6500 Oil Pressure Monitoring
6600 Excitation Control
6700 Speed dependent
Fuel Limitation 1
6800 Speed dependent
Fuel Limitation 2
6900 Speed Notches
Speed dependent Load
Limitation
7000
7100
7200 Pump Map
7300
7500
7600
7700
7800
7900 Temperature Sensors
Feedback
