5 Configuring the Governor with the Hand Held Programmer
The programmer's display is illuminated to ensure legibility in insufficiently
lighted environments.
Note

5.2 The Control Panel

The programmer's control panel is divided into several groups some of which are
distinguished by different background colors. In addition to their standard functions, a
number of keys are assigned a second function which is denoted by the blue legend and
activated by the topmost left key [2nd]. Keys exhibiting exclusively blue captions have no
effect unless in combination with the [2nd]-key.

5.2.1 The Standard Functions

ERRORS
PID
PARAM DISPLAY
between the different lists (standard functions). In doing so, the last-selected list item is
kept in memory.
Example: If the parameter 10 SPEED_MIN1 had been accessed while working in the
parameter list (PARAM) and if after switching to the function list (FUNCT) any
parameters had been altered there, then on returning to the parameter list (PARAM) the
parameter 10 SPEED_MIN1 would be displayed again.
22
1...
PID
2nd
PARAM
CLEAR ERR
ENGINE
STOP
7
SAVE
DATA 4
GET
DATA
1
SEND
DATA
0
MASK
VALUE
ON/OFF
DROOP
SPEED
These keys (background green) permit to switch
FUNCT CURVES
2000...
4000...
ERRORS
SPEED
DISPLAY
FUNCT
ERASE ERR
ERASE BLK
8 9
ACT ADJ
5 6
3
2
+/-
.
CE
×10 ×10
-
+
6000...
DROOP
CURVES
BEGIN LIST
ON/OFF
END LIST
NUMBER
NEXT
LAST
ENTER
Figure 3: The Control Panel
