ASL INTERCOM V400 Installation Manual page 18

2 Connection
Figure 13 Rear of V400 with SSINT and LSDDC Interface Cards (Example)
AC MAINS INLET
L E N
AUXILIARY DC SUPPLY OUTPUT
BATTERY CONNECTOR
GND REMOTE BATTERY
ON/OFF
1 2
A1
3
4 5
N/C N/O
COMM
BATTERY +
FAULT RELAY
V400 – Installation Guide
SSINT
MAINS SUPPLY: IEC 60320 STANDARD PLUG (MALE)
Signal
L
E
N
Mains supply: European standard 230 V AC ±10% / 50-60Hz
Fuse: T6.3A L 250 V
AUXILIARY DC SUPPLY OUTPUT: 2 -WAY PLUGGABLE WAGO CAGE CLAMP (FEMALE)
Signal
"+"
"-"
BATTERY SUPPLY: MIXED CONTACT 7W – 2 (MALE)
Pin No
A1
A2
A2
1
2
3
BATTERY -
4
5
U-0398-0607.doc – Issue: 03 complete, approved
LSDDC
Description
Live
Earth
Neutral
Description
100 V line audio output to loudspeaker circuit
100 V line audio output to loudspeaker circuit
Description
Battery Positive
Battery Negative
Ground Terminal
Remote battery ON/OFF
NC Fault Relay Contact
Common Fault Relay Contact
NO Fault Relay Contact
Page 18 of 24
LSDDC LSDDC
