ASL INTERCOM V400 Installation Manual page 10

Figure 4 Installing the Amplifier Modules into the V400
MODULE SIDE PANELS MUST
!
!
LOCATE IN MAINFRAME SLIDES
M200
1
4 x M100 CONFIGURATION :
M100 M100 M100
1
2 x M200 CONFIGURATION :
M200
1) The mainframe does not need to be fully populated with amplifiers, for example three M100 amplifiers could be fitted, or a single M200 amplifier.
5. If the rack is to be transported, then secure the amplifier modules to each other and to the
mainframe sides using transit screws; see Figure 5.
Do not transport partially equipped mainframes. Either remove all amplifier modules, or fix all
! !
modules in a fully populated mainframe using transit screws.
V400 – Installation Guide
M200
STANDARD CONFIGURATIONS:
M100
M200
U-0398-0607.doc – Issue: 03 complete, approved
(1 x M200 shown as example.)
1 x 200 W + 2 x 100 W CONFIGURATION
M200
1 x M400 CONFIGURATION:
Page 10 of 24
1
:
M100 M100
M400
