- Page 1 User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera Document Version: 1.0 Date: 2012.12 Introduction This document mainly introduces the functional features, installation process and access methods of mini PTZ dome IPC.
- Page 2 Important Notices Thanks for selecting our company’s IPC. Before use, please read through the user’s guide to avoid any unnecessary damage! All functions depend on the actual product. Since the product is subject to updating, our company is not responsible for any difference from this guide and not liable for any dispute over different technical parameters from this guide.
-
Page 3: Table Of Contents
Table of Contents Table of Contents 1 Overview........................ 1 1.1 Product Description ..................1 1.2 Product Features ..................1 1.3 Technical Parameters ................... 3 1.4 Product Appearance ..................5 1.5 Connecting Terminal ..................7 1.6 Basic Procedure ................... 8 2 Installation and Network Configuration ............9 2.1 Hardware Installation ................... -
Page 5: Overview
Overview 1 Overview 1.1 Product Description The mini intelligent high-speed dome IP camera is developed using state-of-the-art technologies and features high-performance digital signal processing (DSP). It is a high-tech monitoring product integrated with a zoom lens, a universal variable-speed Pan Tilt Zoom (PTZ), and a digital decoder. This series camera features all-digital control and simple design, which minimizes inter-component connections, improves system reliability, and facilitates installation and maintenance. - Page 6 User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 Provides the power-off memory function, which enables the camera to restore to the original working status after it is powered off and then restarted, thereby improving system security and reliability ...
-
Page 7: Technical Parameters
Overview Support of the proportional zoom function and auto adjustment of the rotational speed according to the lens zoom multiple Wire coming out from within, to better protect the wire Double web indicator lamps for easy judgment of web status ... - Page 8 User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 Aperture Automatic aperture; the electronic mode is preferential Focus Automatic focusing; the electronic mode is preferential Infrared projection 25 m～30 m Video Coding Primary Processor Hi3512 Operating System Embedded Linux Video Compression Algorithm H.264 main profile level 3...
-
Page 9: Product Appearance
Overview degree Scan Mode Three scan modes: automatic /random/preset position cruise path Preset Position Cruise 6 preset positions, with each one storing up to 16 presets Track Memory 2-track memory Pelco-D、Pelco-P RS-485 Working Environment DC12V，1.5A Input Power POE Ethernet power supply: comply with 802.3af regulation (optional) Maximum Power Consumption -10~+50 °C Working Temperature... - Page 10 User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 Wall-mounted Pending mounted ZKSD422: Mini IR PTZ dome IPC Dimensional Drawing (in mm) (the ZKSD422 mini IR PTZ dome IPC is used as an example )
-
Page 11: Connecting Terminal
Overview 1.5 Connecting Terminal Power Interface: used for connecting the power adapter. The voltage of series products is DC12V AC and the current is not lower than 1.5A. Other power is not allowed, in order to avoid damage of the cameras. Network Interface: 10/100M self-adapting Ethernet interface is used to connect the camera with various network equipments, such as, switch, router and hub. -
Page 12: Basic Procedure
User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 1.6 Basic Procedure Unpack and check whether any component is missing; Connect the camera to computer by means of patch cable; If your computer IP is in a network section different from camera IP, please set it to the same network section as camera IP, such as, 192.168.1.87. -
Page 13: Installation And Network Configuration
Installation and Network Configuration 2 Installation and Network Configuration 2.1 Hardware Installation Installation Notices: Read through the guide for installation prior to installation. Check whether any component is missing against the packing list, if yes, please contact your supplier. Wire during power off. - Page 14 User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 Please use the power (voltage 24V AC and rating current no lower than 1.5A) provided by the factory for the cameras. Much higher or lower voltage and direct current power may cause the camera failure.
- Page 15 Installation and Network Configuration Ambient temperature: -10 ℃ ~ +55 ℃; ambient relative humidity: 10% ~ 85%RH. (10) Please keep the lens and transparent cover clean. If the transparent cover is dirty, please wipe it with clean soft cloth. (11) Do not let the cameras aim at intense light source for long period of time, in order to avoid the CCD failure, which results in no images or distorted images displayed.
- Page 16 User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 ① ② ③ Pendant mounting (Unit: mm): Attach the installation template sticker to the wall on which the camera will be installed and drill holes as required by the template.
-
Page 17: Network Connection
Installation and Network Configuration 3. Drive three screws into the screw holes on top of the mini high-speed dome by half, align the dome with the notch of the base, continue to drive the screws into the screw holes of the base, and tighten the screws. 2.2 Network Connection The device can be connected to network in two ways. - Page 18 User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 Notice: 1) The default IP address is “192.168.1.88” and the default HTTP port is 80. If needed to change IP address or port, refer to Network Setting in WEB Server User Manual.
-
Page 19: Accessing Device
Accessing device 3 Accessing device There are 4 methods can be used to access the device: WEB Browser, RTSP Media Player, Mobile Phone and Video Surveillance Software (ZKiVision client software). 3.1 Using WEB Browser Open a browser, type in the dynamic domain name or IP address of the device (e.g. -
Page 20: Using Rtsp Media Player
User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 Note: When accessing the device via browser for the first time, it is necessary to download the ActiveX. More details about how to use browser for video surveillance, please refer to WEB Server User Manual in the supplied CD. - Page 21 Accessing device Type in the network URL in the form of rtsp://<IP address>:<RTSP port>/<stream code>. Click “Play” and the media player will play the real-time video of the device.
-
Page 22: Using Mobile Phone
User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 Note: 1) The default RTSP port of device is 554. If it must be modified, please contact the network administrator or professional. 2) If it is necessary to learn about how to use RTSP media player for video surveillance, please refer to WEB Server User Manual in the supplied 3.3 Using Mobile Phone... - Page 23 Accessing device Choose “Device List” and click “Add” to add devices, type in the user name, password, domain name and port of the device, click “Save” to complete it.
-
Page 24: Using Video Surveillance Software
User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 Choose “Live View” on the initial interface, click the cell and click again to select the device to play its live video. Note: 1) The operating system of mobile device must be Android or iOS or BlackBerry. - Page 25 Accessing device monitoring can be started. If needed to learn about how to use the video surveillance software, refer to ZKiVision Client Software User Manual in the CD.
-
Page 26: Extended Functions
User’s Manual for ZKSD4 Series Mini PTZ Dome IP Camera V1.0 4 Extended Functions The mini PTZ dome IP camera supports a maximum of 255 presets, among which presets 90 to 130 and preset 255 are used for special functions.
