- Page 1 Configuration Manual Facial Capture & Identification Camera Series Version: 1.0.2 Date: 12/29/2018 Applicable model: FC700, FI700, FC710-L,FI710-L, FI710...
- Page 2 All rights including intellectual or industrial property rights in any information, content, pictures, graphics, materials, data or processes disclosed or discussed in this manual shall belong to ZKTeco co., LTD and its subsidiaries (hereinafter the "company" or "ZKTeco"). No group or individual may take excerpts of, copy, translate or edit all or part of this manual by any means without written permission from the company.
- Page 3 Photographs, graphics, diagrams, and illustrations provided in the manual are for reference only. Release history Date Version Change 2018/9/18 V1.0 New release version Contacts Email: sales@zkteco.com For additional offices around the world, see www.zkteco.com corporate offices. Facial Capture & Identification Camera Series Configuration Manual...
-
Page 4: Table Of Contents
Content INSTRUCTION ..........................8 1. INTERNET CONNECTION ......................8 THROUGH DIRECT CONNECTION ..................8 CONNECT VIA A SWITCH OR ROUTER ................8 2. LOGIN WEB CAMERA ......................9 INSTALL PLUG-INS ......................9 2.1.1 PRE-INSTALLATION PREPARATION OF PLUG-INS ............9 2.1.2 Ping camera ......................... 9 REASONS FOR NOT LOADING PLUG-INS ................ - Page 5 FACE RECOGNITION(ONLY FI710) ..................26 5.2.1 Recognition ....................... 26 5.2.1.1 Face Group Management ................... 26 5.2.1.2 Linkage Alarm ..................... 29 5.2.1.3 Recognition Record .................... 30 6. LOG ............................30 LOG SEARCH ........................30 6.1 LOG BACKUP ........................31 7. SETUP ............................. 31 LOCAL ..........................
- Page 6 9.1.1.4 White Balance Mode ....................44 9.1.1.5 Image Enhance ....................... 45 9.1.1.5.1 Denoise ........................ 45 9.1.1.5.2 Scene ........................ 45 9.1.1.5.3 Environment(only FI710) ..................46 9.1.1.6 Video Adjust(only FC700, FI700) ................47 10. VIDEO AND AUDIO ....................... 47 STREAM SETTING ......................47 10.1 ......................47 10.1.1 Video...
- Page 7 ......................59 11.3.1 WIFI 12. EVENT ........................... 61 Ordinary Events ...................... 61 12.1 ......................61 12.1.1 Relay-in 12.1.2 Relay-out ......................62 12.1.3 Abnormal ......................63 Video Detect ......................64 12.2 12.2.1 Motion Detect ..................... 64 13. STORAGE ..........................65 Plan Config ......................65 13.1 ......................
-
Page 8: Instruction
FC700/FI700/FC710-L/FI710-L/FI710 Series cameras share a set of WEB architecture. Except for the inapplicable parts (such as FI700/FI710-L/FI710 comparison, the relevant description is not applicable to the pure camera FC700/FC710-L/FC710, such as hardware limitations, such as inadequate hardware capabilities to support related functions), the other parts are in principle on a main line, but not in rows. -
Page 9: Login Web Camera
2. Login Web Camera 2.1 Install plug-ins 2.1.1 Pre-installation preparation of plug-ins The camera is connected to 12V power supply after accessing the LAN through the network cable. After one minute of power-on, the camera IP address is searched by Device Manage management software. - Page 10 successfully: Users have anti-virus software installed in their computers, and IE plug-ins are mistaken for viruses that lead to interception. In this case, users only need to temporarily shut down the anti-virus software, and then open it after the plug-in is installed. ...
- Page 11 security level customization, as shown in the following figure. Enable to download and install the Activex control, and plug-ins, as shown in the figure below. Make sure to refresh Internet explorer browser after application, start to download and install Internet explorer control. Facial Capture &...
-
Page 12: Web Login Camera
2.3 WEB Login camera 2.3.1 First WEB Log-in Camera Step 1. In order to enable devices to access the network smoothly, please set the IP address of the computer and the device to the same network segment before accessing the device through the IE browser. - Page 13 Step 3. After the administrator password setting is completed, the system enters the WEB main interface, prompts the installation of plug-ins, and clicks "Please click here to allow the download of plug-ins". Step 4. The system pop-up file download box allows the plug-in to be installed or saved directly according to the need.
-
Page 14: Non-First Web Logon Camera
2.3.2 Non-first WEB logon camera Step 1: Open the IE browser, enter the IP address of the device in the address bar, press the Enter key, and the WEB login interface will be displayed. Step 2. Enter the user name and password and click "Log in" to enter the main WEB interface. -
Page 15: Live
3. Live 3.1 WEB Page introduction The camera supports accessing devices, configuring device parameters and managing devices through Web pages. After successful login to WEB, default access to the monitoring interface, Web page layout and description as shown in the figure. 3.2 System menu bar Function Instruction... -
Page 16: Common Toolbars
For various configurations of the system, please refer to the configuration Setup section for details. Used to display alarm information. Alarm Display the current logged-in user information, where you can modify the Admin user password. You can log out after clicking. For more details, see the logout section. Exit 3.3 Common toolbars Function... - Page 17 Background map button: Background image display switch. When the background image button is selected, the snapshot pane will be displayed. After checking "Show Background Image" in "Face-Overlay and Graphics", the Background Image button can be selected, otherwise the button will be gray. Show the small chart selection box: After checking, a small face image display pane will appear in the WEB interface.
-
Page 18: Snapshot Face Picture Preview Bar
3.4 Snapshot Face Picture Preview Bar Number: The captured face images are arranged in order from right to left. Pictures: The captured pictures are sorted from right to left according to the time. The time when the pictures are captured is shown below the picture. 4. -
Page 19: Video Download Function
Stop button: Click the button to stop playing the video. Next button: Click the button and jump to the next frame to play the video. Slow in button: Click the button and the video will play slowly. Quick release button: Click the button and the video will play faster. - Page 20 query interface. The picture interface can query, preview and download the picture files stored in the camera SD card. The interface is shown in the figure. After setting the start and end time of the query on the interface, click Search to display the image files of that time in the picture information list below the interface.
-
Page 21: Picture View Function
4.5 Picture view function Double-click the file in the list to view the snapshot. 4.6 Image download function Function Instruction Check the image you need to download, click the "Download" button, you can Download pop up the save path selection,select the path and click OK, the checked file will be downloaded and stored in the path. -
Page 22: Face
5.Face 5.1 Face Capture 5.1.1Track and Capture The overlay and snapshot interface is used to set up the overlay information and to configure the snapshot. The interface is shown in the figure. Instruction Function After checking "Overlay Tracking Information", the monitoring interface Track Info will superimpose the target tracking box, and the button of the monitoring interface's rule tracking box will change from grey state to... - Page 23 Function Instruction After checking the "detection rule enablement", the system will turn on the Detect Rule Enable intelligentfacedetectionfunction.Ifthisfunctionisnotturnedon,all related functions of smart face will not beused. Snapshot Enable After checking "Capture Enables", the system will turn on the facial capturing function. When "Video Enabling"...
-
Page 24: Face Param
5.1.2.2 Face Param Face parameters are used to set the mode, parameters and boundaries when capturing. The interface is shown in the figure. Function Insturction Face Confidence After checking "Face Belief", a round of "non-face" judgment will be pushed out before the face capture. For example, the false grasp of non-face such as wheels, animal faces and so on can be filtered out by this function. - Page 25 1.N = 1. Once the recognizable boundary is reached, a face image can be captured and pushed out. 2.N = 2. The first image is a face image with recognizable boundary, and the second one is a face with 3 points higher than the previous image quality score.
-
Page 26: Snap Cutout
5.1.3 Snap Cutout Matting configuration interface is used to set the type of face matting. The interface is shown in the figure. Function Instruction Face Cutout After checking "face matting", snap a small picture as a face map. Half Body Cutout After checking "half-body matting", snap the small picture as a half-body picture. - Page 27 Click "Select Cloth Protection" and fill in the name of the face in "Face Name". "Recognition threshold" defaults to "73" and "comparison upper limit" defaults to "1". If you want to adjust the size of "recognition threshold" and "comparison upper limit", you can enter the value you want to adjust in the corresponding box.
- Page 28 successfully enter the face database. Click "Search" to find the list of people who have entered the face. "Batch addition" can add multiple faces at the same time. "Collection" is used to collect face images and information. Click "Collection" to display the interface as shown in the figure.
-
Page 29: Linkage Alarm
"Unbinding" is used to unbind the face information in the face database. Check before you want to unbind information“ ”,click Unbound to unbind the selected information. “ ”is the return key, it is used to return to the previous level. 5.2.1.2 Linkage Alarm The linkage alarm interface is used to set the type of alarm in face recognition. -
Page 30: Recognition Record
automatically checked. Wiegand Channel Currently, only "Wigan Channel 1" is supported. By default, no Wigan Config Channel is checked. 5.2.1.3 Recognition Record Recognition record interface is used to query device recognition record. Click on the Recognition Record to enter the Recognition Record Interface. Recognition records can be queried according to face database, recognition restriction and time period. -
Page 31: Log Backup
6.1 Log Backup Log backup interface is used to backup and store past identification records. Click the "Backup" button to automatically pop up the Storage Path Selection Box, which can backup the log to the selected local directory. 7. Setup Local 7.1.1Local Config The local configuration interface is used to configure the path to capture and record... -
Page 32: 2Video Watermark
Function Instruction Monitor Picture The path where the captured image is stored locally during monitoring, click Browse to change the path, and click Open Folder to open the folder under the archive path. Storage Path The path where the recorded video is stored locally during monitoring, click Browse to Monitor Video Storage change the path, and click Open Folder to open the folder under the archive path. -
Page 33: Local Picture
Browse button: Click this button, select the video folder on the local PC as needed, and click review OK to display all the videos in the folder in the video list. 7.1.3 Local Picture The local picture interface is used to select the local picture file and view the picture file. The interface is shown in the figure. -
Page 34: System
8. System 8.1 System Config 8.1.1 General Info The basic information interface is used to view and set up the system information of the device, including the name of the device, the model of the device, the version of the device and so on. -
Page 35: Date
8.1.2 Date The date interface is used to set the time zone, time and daylight saving time of the device. The interface is shown in the figure. Function Instruction Timing zone The time zone where the equipment is located. System time Current system time of equipment. -
Page 36: Communication Configurations(Only Fi710)
port The current port name of the device Calibration time For setting the calibration interval of equipment, the interval can be set to interval ~ 1440 minutes, default to 60 minutes. 8.1.3 Communication Configurations(only FI710) The serial interface is used to configure the parameters of RS485 serial port and to match the interface. -
Page 37: Account
Account 8.2.1Account 8.2.1.1 Add User In the user management interface, click the "Add" button to enter the add user interface. In this interface, enter the user name and password. User level can select "operator" and "ordinary user". After checking the user rights, click "Save" to complete the user add. The interface is shown in the figure. -
Page 38: Modify User
8.2.1.2 Modify User Select the user line that needs to be modified in the user management interface, and click the "Modify" button to enter the Modified User Interface, where passwords, user levels and permissions can be changed. The interface is shown in the figure. 8.2.1.3 Delete User Select the user that needs to be deleted in the user management interface, click the Delete button to pop up the confirmation dialog box, and click OK to delete the user. -
Page 39: Safety
8.3 Safety 8.3.1 IP Address Filter IP address filtering interface is used to set the filtering mode of IP address, add, modify and delete IP address. The interface is shown in the figure. Function Instruction IP address filtering can be divided into no, permission and prohibition. No: Indicates that IP address filtering is not enabled IP address filtering Allow: Indicates that only IP added to the IP address column is allowed t... -
Page 40: System Maintenance
In the security management interface, clicking the Add button will enter the Add IP interface. Select the IP that needs to be modified in the IP address column, and clic Modify the "Modify" button to enter the Modify IP interface. Select the IP that needs to be deleted in the IP address column, click the Delete Delete button to pop up the confirmation dialog box, and click OK to... -
Page 41: Telnet
Parameter Parameter maintenance includes parameter import and export. This functio maintenance can facilitate users to set the same parameters for equipment. System upgrade includes upgrade file import and upgrade. When upgrade system, first click "import" to import upgrade file, then click "upgrade", syste System upgrade upgrade automatically. -
Page 42: Day/Night Switching
Function Instruction Brightness button: brightness Used to adjust the overall brightness of the image, the bigger the value, the brighter the image. Contrast button: contrast ratio To adjust the contrast of the image, the bigger the value, the bigger the brightness contrast of the image. Saturation button: saturation Used to adjust the brightness of image color, the bigger the value... -
Page 43: Shutter
9.1.1.3 Shutter The shutter setting interface is used to set shutter modes such as photometry, exposure, gain and aperture when capturing faces. The interface is shown in the figure. Function Instruction Metering mode: Global photometry: The default setting is used to measure the brightness o Metering the whole picture area and adjust the brightness of the whole picture intelligently according to the measurement results. -
Page 44: White Balance Mode
adjust the brightness of the whole picture intelligently according to the measurement results. If the test area is lighter, the whole darkens; if the tests area is darker, the whole brightens. Backlight compensation: Enabling backlight compensation will enhance the brightness of the dark part of the picture backlight. Strong light suppression: When there is a certain degree of strong light in the picture, the use of strong light suppression can prevent the picture from overexposure. -
Page 45: Image Enhance
It is divided into automatic, high color temperature, low color temperature automatic color temperature and local automatic. The local automation automatic function is suitable for the user to draw the region separately under the complex color temperature environment for white balance processing. Custom color temperature can be set, and the red gain and blue gain can be adjusted according to the ambient color temperature. -
Page 46: Environment(Only Fi710)
Function Instruction For switching different scenario modes, scenario modes include no Switching mode switching, switching according to brightness, forcing daytime, forcing other and forcing night. Used to switch to different scenarios to modify the corresponding scene parameters, divided into day, night and evening. To adjust the sharpness of image edge, the bigger the value, the more obvious the edge of the image, but when the value is set larger, the Sharpness pattern... -
Page 47: Video Adjust(Only Fc700, Fi700)
9.1.1.6 Video Adjust(only FC700, FI700) The video adjustment interface is used to adjust the angle of the video interface. Customers can adjust the video interface in three modes: flip, mirror and rotate according to their needs. The interface is shown in the figure. -
Page 48: Snapshot
Function Instruction Bitstream type It is divided into main stream, auxiliary stream 1 and auxiliary stream 2. Enable Check Enables by default. Customers can choose according to the requirements of video clarity The higher the resolution, the higher the bandwidth requirement of the Resolving power network. -
Page 49: Audio
Function Instruction Resolving power Customers can choose according to the requirements of video clarity. The higher the resolution, the higher the bandwidth requirement of the network. Different product models and different resolutions are supported. Please refer to the actual page display. The maximum resolution of the picture is based on the specific product. -
Page 50: Audio Input
Bitstream type This option is not set and defaults to "main stream" Audio coding At present, PCM, G. 711A and G. 711Mu are the supported coding modes. Sampling frequency At present, 8K000/16bit and 16000/16bit are optional. / depth 10.1.3.2 Audio Input Audio input interface is used to adjust channel number and device mode. -
Page 51: Interest Area
Function Instruction Channel number This option is not set and defaults to "1". volume To adjust the volume of the audio, click "" to reduce the volume, and click " " to increase the volume. 10.1.4 Interest Area The region of interest interface is used to set up the region of interest, with a maximum of four regions. -
Page 52: Water Mark
Refresh Used to refresh the set region of interest confirm Used to determine all set regions of interest. empty Used to delete all set regions of interest. 10.1.5 Water Mark You can customize the content of the watermarking, click Enable and make sure that the watermarking will be added automatically in the video. -
Page 53: Osd Config
Comfirm Used to determine all set regions of interest. 10.2 OSD Config 10.2.1 Video OSD Video OSD interface is used to set OSD information of video channel, including channel name, date, week, etc. The interface is shown in the figure. Function Instruction Customers can display OSD information by checking "Display Name"... -
Page 54: Snap Osd
10.2.2 Snap OSD The picture OSD interface is used to set the OSD information of the picture, including time, week, place, etc. The interface is shown in the figure. Function Instruction Increase picture title: Client can choose any area of the picture to dra the mouse to increase the picture title. -
Page 55: Network
11. Network 11.1 Network 11.1.1 TCP/IP The TCP/IP configuration interface is used to set the device's login IP. IPv4 supports static IP and DHCP to dynamically acquire IP. The interface is shown in the figure. Function Instruction Network cards are divided into eth0 and wlan0. eth0: Cable network card. -
Page 56: Connection
default gateway will become unset, and the system will automatically acquire IP. IP address Device IP address. Subnet mask The subnet mask corresponding to the device IP address. Default gateway The default gateway corresponding to the device IP address. Preferred DNS server IP address. -
Page 57: Advanced Config
will. When there is port conflict and port number needs to be changed, please modify the instructions in the table below. Function Instruction HTTP port When using browser to log in, you need to add a modified port number after th address. -
Page 58: Qos
11.2.2 Qos The Qos interface is used to configure the priority of video forwarding, ranging from 0to 63. When the value is 46, the Qos interface is accelerated.The interface is shown in the figure. 11.2.3 SNMP The SNMP interface is used to set up the SNMP server and SNMP V1/V2/V3. The interface is shown in the figure. -
Page 59: Wifi(Only Fi710)
Function Instruction SNMP server Set server port number, Trap address and other parameters. settings SNMP V1/V2/V3 According to different versions of SNMP network management protocol, it can b checked and enabled separately and set accordingly. 11.3 WIFI(only FI710) 11.3.1 WIFI WIFI interface is used to set up and connect wireless network, which is convenient for users to transmit video images through wireless network when wiring is inconvenient. - Page 60 Function Instruction Enable After checking "Enable", open the WIFI function. Scan add 1. Click the "Scan" button, and the list will show the hot spots of wireless network i the current device environment. 2. Click any item in the list and the selected WIFI name, authentication mode an encryption type will be displayed below the interface.
-
Page 61: Event
12. Event 12.1 Ordinary Events 12.1.1 Relay-in The alarm input interface is used to configure the external alarm channel, sensor type and alarm time. The interface is shown in the figure. When setting alarm linkage to an alarm output channel on other pages, the alarm function must be activated on this page before it can take effect. -
Page 62: Relay-Out
Alarm output delay After the end of the alarm, the alarm will be extended for a period of time to stop. Customers can set the time according to their needs. Alarm output At present, only one alarm output is supported. channel Deployment time Click the "Settings"... -
Page 63: Abnormal
Mandatory output Whether or not the alarm is generated by the regular opening and closing and the face snapping, the system will always output the alarm. 12.1.3 Abnormal The abnormal interface is used to set the abnormal type, video recording and output of the alarm which will trigger the alarm. -
Page 64: Video Detect
3. Alarm output channel: At present only support alarm output channel 1. 12.2 Video Detect 12.2.1 Motion Detect Function Instruction Use the mouse to preview the small window on the left to delineate the motion detection area, and then check to enable, then start the motion detection in the selected area. -
Page 65: Storage
13. Storage 13.1 Plan Config The plan configuration interface is used to set the video mode and related parameters, as shown in the figure. Function Instruction Video recording modes are divided into automatic, manual and closed modes. Auto: Auto video includes timing video and alarm video. Timing Video: In the period of deployment, the system will automatically make timing video. -
Page 66: Storage
Video Packing Time Set the packing time for each video file. Length 13.2 Storage 13.2.1 Disk Storage The disk storage interface is used to display various storage status information of the local SD card/TF card. The interface is shown in the figure. Function Instruction There are "Open"... -
Page 67: Net Storage
13.2.2 Net Storage The network storage interface is used to display video and picture online storage information, including the interface as shown in the figure. Function Instruction Click Add to add a network storage protocol. Delete Click Add to delete the network storage protocol. Reset current Click to reset the FTP protocol settings to the default state. -
Page 68: Peripheral Config
the device can automatically continue to upload to the set server. server address Used to set the FTP protocol server address. 14. Peripheral Config 14.1 Peripheral Config 14.1.1 IO Function IO port function interface is used to set the output and input functions of peripheral devices. -
Page 69: Terrace Connect
Function Instruction IO port At present, IO port only supports IO port 1. At present, there are three working modes: forced shutdown, forced open Working mode and automatic. 15. Terrace Connect 15.1 GB28181 15.1.1 GB28181 GB28181 refers to "Technical Requirements for Transmission, Exchange and Control of Security Video Surveillance Networking System"... -
Page 70: Cloud Service
15.2 Cloud Service The cloud service interface is shown in the figure. Check Enables. After setting the parameters, click Save to complete the settings. 15.3 ZhongKong At present, the interface of the central control platform only supports server 1. Check Enabling. -
Page 71: Alarm
16. Alarm The alarm interface is used to set alarm type, alarm operation, alarm sound and query alarm log. The interface is shown in the figure. Function Instruction At present, the type of alarm only supports IP conflict. When the device I Alarm type conflict is checked, the alarm will start. -
Page 72: Exit
Log list Browse and query alarm records in this list. 17. Exit As shown in the figure, by clicking the "Exit" button in the upper right corner of the WEB interface, the system will return to the login interface and re-enter to the required login. Facial Capture &... - Page 73 Facial Capture & Identification Camera Series Configuration Manual © Copyright 2018. ZKTeco Inc. ZKTeco Logo is a registered trademark of ZKTeco or a related company. All other product and company names mentioned are used for identification purposes only and may be the trademarks of their respective owners. All specifications are subject to...
