- Page 1 ROCKETLINX ES7510 Industrial 10-Port Gigabit Managed PoE Plus Switch Quick Installation Guide www.comtrol.com 2000546 Rev B...
- Page 2 See the Comtrol web site for detailed product specifications. Installation Overview You can use the following overview to install the RocketLinx ES7510. If you need more detailed information, you can refer to the RocketLinx ES7510 User Guide, which contains detailed installation and configuration information.
- Page 3 802.3at (max.) 262W 3. Connect a ground wire between the chassis and earth ground to ensure that the RocketLinx ES7510 is not damaged by noise or electrical shock. a. Loosen the earth ground screw on the right side of the RocketLinx ES7510.
- Page 4 Mount the ES7510 You can use the following procedure to mount the RocketLinx ES7510 on the wall. Attach the mounting brackets to the RocketLinx ES7510 by using the screws provided in the bracket mounting kit. To avoid damage to the RocketLinx ES7510 circuitry, make sure that you use the screws included in the bracket mounting package to attach and tighten the brackets onto the RocketLinx ES7510.
- Page 5 All the Fast Ethernet ports automatically detect the signal from the connected devices to negotiate the link speed and duplex mode. Auto MDI/MDIX allows you to connect another switch, hub, or workstation without changing straight-through or crossover cables. Crossover cables cross-connect the transmit lines at each end to the received lines at the opposite end. Switch Router or PC Switch...
- Page 6 Web browser Command Line Interface (CLI) using one of these methods: - Serial console port by connecting the RS-232 console cable that was shipped with the RocketLinx ES7510 to a system COM port - Telnet - Secure shell (SSH) The default IP address of the RocketLinx ES7510 is 192.168.250.250.
- Page 7 Select the IP Settings/Modify IP menu item to commit the IP address and Netmask change to the RocketLinx ES7510 switch. 5. Open a web browser and enter the IP address of the RocketLinx ES7510. For example: http://192.168.250.250 or https://192.168.250.250.
- Page 8 Comtrol Customer Service Contact Method Web Address or Phone Number Support http://www.comtrol.com/pub/en/support Downloads ftp://ftp.comtrol.com/html/ES7510_main.htm Web Site http://www.comtrol.com Phone 763.957.6000...
