Penton - TV Unit
Assembly Instructions
- Please keep for future reference
609/7093
609/7103
Dimensions
Width - 85cm
Depth - 40cm
Height - 57cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 08456 400 800
Issue 1 - 17/10/12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Home Penton TV Unit 609/7093
Summary of Contents for Argos Home Penton TV Unit 609/7093
- Page 1 Penton - TV Unit Assembly Instructions - Please keep for future reference 609/7093 609/7103 Dimensions Width - 85cm Depth - 40cm Height - 57cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400 800 Issue 1 - 17/10/12...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below 7 Back panel (81.2 x 27cm) 1 Top panel (85 x 40cm) 8 Top front frame (68.6 x 6.5cm) underside 9 Bottom front frame x 2 (68.6 x 6.5cm) 2 Base panel (79.4 x 28.4cm) 10 Cross rail...
-
Page 4: Tools Required
Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 Assembly Instructions Step 1 Fixing right front frame to the right side panel (Two people required for an easier assembly) Position right front frame to the right side panel through joints. Yes! Note: 50mm Before fixing the 100mm blocks into place it is important to ensure that the slot and 250mm...
- Page 6 Assembly Instructions Step 3 Insert dowels into the indicated parts. Step 4 Fixing side drawer runner on right side panel. Fit side drawer runner first in the front frame then after in the side panel as shown. Attach side drawer runner using screw Repeat step 4 for the...
- Page 7 Assembly Instructions Step 5 Assembling parts. Put parts together as shown in the diagram. Step 6 Insert the assembled frame and top front frame into the holes on left side panel Note: The hole position. Step 7 Fixing base panel. Fit base panel to the Note: The...
- Page 8 Assembly Instructions Step 8 Attention: Fixing middle drawer runner. Fit middle drawer runner to the vertical frame then fix using screw Attention: Make sure middle drawer runner is positioned as shown in the diagram prior to fixing. Step 9 Attention Base panel Fixing back column.
- Page 9 Assembly Instructions Step 11 Fixing right side panel. Place right side panel properly ensuring dowels and front frames are all fitted into their holes at the same time. Fix base panel cross rail to the side using screws Fix bottom front frame to the right and left side panels using screws as shown in the...
- Page 10 Assembly Instructions Step 14 Drawer assembly. Attach drawer sides to the drawer front using screws Slide drawer bottom into slots on drawer sides and position drawer back in place. Holding the drawer back , press the drawer sides and fix them using screws Using bolts attach...
