Maddison Bunk

Assembly Instructions -

Please keep for future reference

805/8906

798/6110

Dimensions

Length - 198cm

Width - 97cm

Height - 165cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800

Issue 1 -12/10/17

Need help?

Do you have a question about the Maddison Bunk 805/8906 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Home Maddison Bunk 805/8906

Page 1 Maddison Bunk Assembly Instructions - Please keep for future reference 805/8906 798/6110 Dimensions Length - 198cm Width - 97cm Height - 165cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800 Issue 1 -12/10/17...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Assemble the item as close • Place the product on flat and • Check you have all the steady surface during use. components and tools listed on to its final position (in the same pages 2 and 3.
Page 3: Components - Parts
Components - Parts Please check you have all the parts listed below Upper corner post x 4 End panel (Upper) x 2 (3.8 x 103.5cm) (97 x 39.8cm) Lower corner post x 4 End panel (Lower) x 2 (3.8 x 66.5cm) (25 x 88.5cm) Rear guard rail Guard rail x 2...
Page 4 Components - Fittings If you have damaged or missing components, 0345 6400 800 call the Customer Helpline: Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 Assembly Instructions Step 1 Preparing corner posts Join upper corner posts and lower corner posts together and secure using fixings Step 2 Assembling side frames Lay one corner post ， an upper end panel and a lower end panel flat on the floor as shown.
Page 6 Assembly Instructions Step 3 Assembling upper guard rail (rear) Rear To assemble the rear guard rail, locate internal bracket inside guard rail as shown. Secure using screw Locate rear guard rail over the end of the internal bracket in guard rail and secure using fixings...
Page 7 Assembly Instructions Step 5 Assembling lower side rails Locate internal bracket inside lower side rail , and secure using screw Slide lower side rail over the internal bracket and secure using screw Note: Lower side rail has an extra hole for the Front ladder fixing, This will Note: Hole for...
Page 8 Assembly Instructions Step 6 Assembling rear guard and side rail Two people are needed here. With help, stand both side frames upright. Assemble the rear guard rail assembly in between the side frames as shown. Note: Do not fully tighten any screws during the assembly.
Page 9 Assembly Instructions Step 7 Assembling front guard At this stage, choose if you want the ladder on the right hand side or left hand side. According to which side you want the ladder, assemble the front guard assembly between the side frames as shown.
Page 10 Assembly Instructions Step 8 Assembling end slats Fit end slats in the very last fixing holes at each end of the bed (top and bottom bunks). Note: The arrow labels slats must point outside. Note: Slats have been labelled for easier identification.
Page 11 Assembly Instructions Step 9 External bracket Assembling middle slats Outside Inside Locate external brackets over the joints in the front and rear guard rails on the top bunk. Note: Depending on which way round you have assembled the front guard rail, external bracket will be on either the inside or outside of the bed.
Page 12 Assembly Instructions Step 10 Assembling slats Assemble remaining slats to both bunks using screws shown .
Page 13 Assembly Instructions Step 11 Attaching ladder Assemble ladder front guard and lower side rail using fixings Fixings are located inside the frame as shown. Plastic plugs can be used to cover the un-used holes in the corner post as shown. Important Once assembly is complete, ensure all...
