Description of the device
4.2
Overview
Reflexomat with touch control and one compressor
1
Main switch
2
Control unit
•
Compressor(s)
•
"Reflex Control Touch" controller
3
"RG" primary tank
10 — English
Reflexomat with Touch controller — 06.07.2016 - Rev. B
4
"SV" safety valve
5
"RF" secondary tank (optional)
6
"EC" expansion line
7
"LIS" level sensor
