Hioki MR6000 Quick Start Manual page 3

Measurement Procedure
The basic measurement procedure is as follows. For advanced use, refer to Instruction Manual
(PDF) in the accompanying CD.
Preparing for measurement
Inspecting the instrument before measurement
Configuring the basic settings for measurement
Choose a sampling rate.
Choose a recording length (shot).
Configuring the input channel settings
Configure the analog channel settings.
Configuring the trigger settings
Configure the trigger settings.
Starting/Stopping measurement
Saving waveform data files
Analyzing waveforms
Scroll through, zoom in, and zoom out waveforms.
Read measured values (with the trace cursors).
Finishing the measurement
(p. 37)
(p. 69)
(p. 70)
(p. 72)
(p. 75)
(p. 77)
(p. 78)
(p. 83)
