Connection and installation manual
Swing gate control unit ST 61A
in combination with traffic light control STA 11
traffic light control STA11 in
enclosure IP 54 (210 x 310 x 125mm)
swing gate control ST 61A and traffic light control STA11
in steel cabinet IP 66 (380 x 300 x 150mm)
Safety Sensor
Dswing gate control ST 61A in
enclosure IP 54 (210 x 310 x 125mm)
Advertisement
Table of Contents
Related Manuals for tousek ST 61A
Summary of Contents for tousek ST 61A
- Page 1 Connection and installation manual Swing gate control unit ST 61A in combination with traffic light control STA 11 swing gate control ST 61A and traffic light control STA11 in steel cabinet IP 66 (380 x 300 x 150mm) traffic light control STA11 in...
-
Page 2: Table Of Contents
January 2019 This manual is the sole property of the TOUSEK Ges.m.b.H. and may not be made available to competitors. All rights reserved. No part of it may be reproduced without our prior written permission. We will not accept liability for any claims resulting from misprints or errors. This edition of the manual replaces all earlier publications of the same. -
Page 3: General Warning And Safety Notes
EU and in the individual countries have to be strictly followed. • The TOUSEK Ges.m.b.H. can not be held liable for any claims resulting from disregards of the laws and standards in force during the installation and operation. -
Page 4: Notes, General Characteristics, Technical Data St 61A And Sta 11
12120370 optional equipment induction loop detector ISD 6 (2-channels) • pluggable radio receiver Swing gate control ST 61A and traffic light control STA11 in steel cabinet IP 66 (380 x 300 x 150mm) power supply 230V a.c., +/-10% 50Hz protection class... -
Page 5: Traffic Light Control Board Sta 11, Function
Function The traffic light control enables in conjunction with a suitable operator control board (eg ST 61A) the automation and control of the gate entry and exit through a traffic light. At the terminals of the traffic light controller separate impulse generators can be connected for „inside“... -
Page 6: Control Board Overview And Terminal Assignment
(rain). rately from the 230V lines (supply, motor, signal light). With ST 61A no limit switch is necessary: terminals 60/61 have to be wire bridged! 230V max. -
Page 7: Connections And Adjustments
Limit switch input Connections (term. 60/61) Important With the control unit ST 61A no limit switch connection at the traffic control unit STA 11 is necessary, instead the terminals 60/61 must be wire bridged! Traffic light outputs GREEN outside outside: GREEN: term. -
Page 8: Radio Receiver (Optional)
(optional) Important • When using a radio receiver in traffic light mode, the receiver is not to plugged into the slot of the ST 61A, but into the slot of the traffic light control STA 11 ! • Disconnect the power supply. -
Page 9: Induction Loop Detector Isd 6 (Optional)
• Reset: average duration of the key press (> 2s), reset the detector, subsequent initialization of all channels. Insert the board of the induction loop detector on the slot (ISD) of the traffic light control unit STA 11. STA 11 - 9 - tousek / EN_ST-61A_08 / 25. 03. 2020... -
Page 10: Swing Gate Control St 61A, Control Board Layout
System plug for optional module drop bolt or electric lock / magnet ( page 26) (VE) 230V a.c. for electric lock/magnet module term. 88/89: for traffic light control connection STA11 - 10 - tousek / EN_ST-61A_08 / 25. 03. 2020... -
Page 11: Terminal Assignment, Connection Notes
3.1 Terminal assignment Swing gate control unit ST 61A Warning • Before taking off the control cover, • The product is not suitable for installation in explosion- hazardous/explosive areas. the main switch must be turned off ! • The inside of the control unit is under tension when •... -
Page 12: Adjustments - Overview
3.2 Adjustments - overview Swing gate control unit ST 61A Programming buttons Adjustments - Overview • The adjustment (programming) of the operating parameters is carried out via four programming buttons and the text display. • Before you can start programming, select the language of the display. You can do this by pressing the + or - and choose the language for the menuas and press ENTER. - Page 13 The menu points courtyard lamp and control lamp will only appear on display if in menu „Additional module“ courtyard lamp/control lamp is selected. ENTER Swing gate control unit ST61A - 13 - tousek / EN_ST-61A_08 / 25. 03. 2020...
-
Page 14: Connections And Adjustments
Power supply may not be connected until all the connections to the control board are finished! • If the control boards are in separated plastic enclosures then the power supply cables must be connected according to the connection plan: - swing gate control board ST 61A page 11 ... -
Page 15: Buttons/Switches
The stop input has no emergency stop function! - In order to ensure the emergency stop function, provide the supply line with an all-pole disconnecting emergency stop switch, that locks after actuation! - 15 - tousek / EN_ST-61A_08 / 25. 03. 2020... -
Page 16: Safety
(contact: terminals 45/48) Safety active: to be selected, if outer photocell should be triggered. not active: to be selected, if outer photocell should not be triggered. - 16 - tousek / EN_ST-61A_08 / 25. 03. 2020... - Page 17 Tousek RLS 620 as safety device transmitter receiver 12/24V 12/24V NC C NO 24Va.c. Important • Jumper J of transmitter and receiver has to be adjusted in the same way. - 17 - tousek / EN_ST-61A_08 / 25. 03. 2020...
- Page 18 radio edge TX310: to be selected if safety sensing edge (8,2kΩ) of main entrance edge 2 should be evaluated with the radio transmission system TX 310. • Connection and detailed information of radio transmission system TX 310 see according manual. - 18 - tousek / EN_ST-61A_08 / 25. 03. 2020...
- Page 19 • The photocell self-test can only be deactivated by selecting „not active“. • The deactivation of the self-test function is only permitted if the safety installations correspond to the category 3 ! - 19 - tousek / EN_ST-61A_08 / 25. 03. 2020...
- Page 20 • Attention: Before carrying out any connection works, the power supply of the gate facility has to be turned off. • Operators´ power supply and sensor cables as well as the capacitors must be connected to the ST 61A control unit acoording to the installation manual.
- Page 21 CONNECTION of operators to control unit black Connection cable with left operator right operator blue colour or number to terminal to terminal brown brown blue or grey black green/yellow - 21 - tousek / EN_ST-61A_08 / 25. 03. 2020...
-
Page 22: Left Leaf
Right leaf The option „soft start“ is only inserted for not active SWING X. With SPIN operator soft start is active: soft start with SWING X. always active! - 22 - tousek / EN_ST-61A_08 / 25. 03. 2020... -
Page 23: Operating Mode
(HSK 1-term.50/52) Mode HSK 2 inside/outside outside active Limit tolerance Operating logic 20 (factory setting) 3–20 adjustable: indicates the tolerance in the end positions (low value = sensitive behaviour). - 23 - tousek / EN_ST-61A_08 / 25. 03. 2020... -
Page 24: Light/Lamps
If the gate is closed, the pilot lamp expires illuminates in open position: Pilot lamp is illuminated as soon as the gate has reached end position open. - 24 - tousek / EN_ST-61A_08 / 25. 03. 2020... -
Page 25: Peripherals
OPEN and CLOSE: locking via motorized locking bar in both end positions of the gate. only OPEN: locking via motorized locking bar only in open position. only CLOSE: locking via motorized locking bar only in closed position. - 25 - tousek / EN_ST-61A_08 / 25. 03. 2020... - Page 26 LIGHT PERIPHERAL / ELECTRIC LOCK • Magnets are driven into the open and closed position of The series resistor (R) is for tousek the gate, the electric lock only in closed position. magnets GD 50 and GD 70.
- Page 27 „T“ with tousek control units ST 51, motor ST 61, ST REX connection „ “ with foreign control units Limit switch closed, if the bolt is retracted DROPBOLT 2 - 27 - tousek / EN_ST-61A_08 / 25. 03. 2020...
-
Page 28: Diagnosis
in this manual. Software version Diagnosis shows the software version and the operator type on the text display Serial number Diagnosis shows the serial number on the text display - 28 - tousek / EN_ST-61A_08 / 25. 03. 2020... - Page 29 - 29 - tousek / EN_ST-61A_08 / 25. 03. 2020...
-
Page 30: Putting Into Operation
Putting into operation Swing gate control unit ST 61A Important: preparation works • Connect control panels, safety devices to the motor under the safety regulations in . Attention: if no stop switch is connected then the terminals 30/31 have to be bridged. - Page 31 $$$$$$$$$$$$$$$$ mainsafety edge2 $$$$$$$$$$$$$$$$ mainsafety edge2 $$$$$$$$$$$$$$$$ $$$$$$$$$$$$$$$$ active right (term. 50/53) adopt $$$$$$$$$$$$$$$$ mainsafety edge2 $$$$$$$$$$$$$$$$ not active adopt right (term. 50/53) $$$$$$$$$$$$$$$$ mainsafety edge2 $$$$$$$$$$$$$$$$ radio edge TX - 31 - tousek / EN_ST-61A_08 / 25. 03. 2020...
- Page 32 $$$$$$$$$$$$$$$$ motor right $$$$$$$$$$$$$$$$ change ? YES $$$$$$$$$$$$$$$$ delay right leaf $$$$$$$$$$$$$$$$ delay right leaf $$$$$$$$$$$$$$$$ $$$$$$$$$$$$$$$$ closing delay adopt $$$$$$$$$$$$$$$$ delay right leaf $$$$$$$$$$$$$$$$ opening delay - 32 - tousek / EN_ST-61A_08 / 25. 03. 2020...
- Page 33 • IMPORTANT: With 1 leaf gate installation, only the operator of the actually existing gate leaf must be activated in the main menu, the other one has to be disabled (deactivated) ! (In Main Menu: Left(Right) leaf / Motor / „Motor OFF“) - 33 - tousek / EN_ST-61A_08 / 25. 03. 2020...
-
Page 34: Troubleshooting Guide
Troubleshooting guide Swing gate control unit ST 61A Error possible reason solution mains voltage missing control of mains voltage as well as of or fuse F1 defective fuse F1 no reaction after emitting a command Display: error stop button check if stop button is properly con-... -
Page 35: Dimensional Sketch Enclosure Ip 54
Dimensioned drawing housing IP54 Swing gate control unit ST 61A • dimensions in mm • Mounting dimensions (back side) We reserve the right to change dimensions and technical specifications without prior notice ! - 35 - tousek / EN_ST-61A_08 / 25. 03. 2020... - Page 36 Buitenheide 2A/ 1 Tel. +32/ 11/ 91 61 60 Ihr Servicepartner: Fax +32/ 11/ 96 87 05 info@tousek.be Tousek Sp. z o.o. Polen PL 43-190 Mikołów (k/Katowic) Gliwicka 67 Tel. +48/ 32/ 738 53 65 Fax +48/ 32/ 738 53 66 info@tousek.pl...
