Summary of Contents for tousek ST 80A
- Page 1 Installation and connection manual Barrier control unit ST 80A, ST 80VA in combination with traffic light control STA 11...
-
Page 2: Table Of Contents
Dimensioned drawing ..........................27 This manual is the sole property of the TOUSEK Ges.m.b.H. and may not be made available to competitors. All rights reserved. No part of it may be reproduced without our prior written permission. We will not accept liability for any claims resulting from misprints or errors. This edition of the manual replaces all earlier publications of the same. -
Page 3: General Warning And Safety Details
EU and in the individual countries have to be strictly followed. • The TOUSEK Ges.m.b.H. cannot be held liable for any claims resulting from disregards of the laws and standards in force during the installation and operation. -
Page 4: Notes, General Characteristics, Technical Data St 80(V)A Und Sta 11
Technische Daten Traffic light control board STA 11 Power supply 230Va.c., +6/-10%, 50Hz Relay load Red/Green traffic light 230V, max. 60W Article no. 12120370 Optional equipment induction loop detector ISD 6 (2-channels) • pluggable receiver - 4 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 5: Traffic Light Control Board Sta 11, Function
• If a further order from the counter side is given with traffic light logic „one side Green“during the green phase/ clearance time, then the barrier/gate remains after the green phase/clearance time open and the Green dis- play changes to the counter side. When the stop button is triggered, the gate stops moving and only opens again with command by either side. - 5 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 6: 2.1 Control Board Overview And Terminal Assignment
(FE) Slot for optional radio receiver (p. 8) • A pole disconnecting main switch with a min. contact gap of 3mm has to be provided. The system must be protected fuse 3,15A T in each case in accordance with applicable safety regula- tions! For connection, adjustment and mainte- • IMPORTANT: The control lines (buttons, radio remote nance works ensure that the electronics control, light barriers, etc.) have to be separated from are not damaged by moisture (rain). the 230 lines (supply, motor, signal light) to relocate 230V max. 60W operator control unit ST80(V)A - 6 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 7: 2.2 Connections And Adjustments
Bus system control unit High Important Bus system • Max. cable length between automation and traffic ST 80(V)A STA 11 light control is 25m. • Cable type e.g.: PVC control cable 2 x 1mm2 YSLY or equivalent. Adjustments • The functions of the traffic light control is determined by the settings of the connected operator control board. These relate to the duration of the green phase and the clearance time, the traffic light at the closed door position (whether or continuous red) and the traffic light system (both sides / one side green). - 7 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 8: Radio Receiver (Optional)
Important • With the use of the 2-channel-receiver the first chan- nel takes over the function for the impulse switch outside and the second channel the function for the impulse switch inside. STA 11 • For programming of receiver please see manual for radio receiver. STA 11 - 8 - tousek / EN_ST-80A_04 / 25. 03. 2020... - Page 9 - 9 - tousek / EN_ST-80A_04 / 25. 03. 2020...
-
Page 10: Barrier Control Unit St 80(V)A, Control Board Layout
(F1) safety fuse F 5A tousek-service-interface (TSI) terminals bus system (e.g. for optional traffic light) (F2) safety fuse F 2A (ISD) Slot for optional I-loop detector (p.23) (Safety or presence loop) - 10 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 11: Terminal Assignment, Connection Notes
• The product is not suitable for installation in explosion-hazardous areas. • An all-pole disconnecting mains switch with a contact opening gap of min. 3 mm has to be foreseen. The barrier facility has to be secured according to the valid safety regulations! • IMPORTANT: The control lines (buttons, radio, photocells, etc.) have to be laid separately from the 230V lines (supply line, motors, signal lamp). PHC-supply motor c o n n e c t i o n The stop input has no emergency stop function! - In order to ensure the emergency stop function, provide the supply line with an all-pole disconnecting emergency stop switch, that locks after actuation! - 11 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 12: 3.2 Adjustments - Overview
The different menu points are indicated as follows: = selectable setting = factory settings = status display shows the menu points which are in the “ BASIC SETTINGS” - 12 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 13: Menus
YES software version display software version serial number display serial number protocol display protocol messages sensor status display sensor At barriers with 6m boom length the settings for speed OPEN/CLOSE must not be more than 90% (= factory setting of ST 80A)! ENTER Barrier control unit ST 80(V)A - 13 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 14: 3.3. Connections And Adjustments
= status display shows the menu points which are in the “ BASIC SETTINGS” • A general status display of all inputs can be found in the menu DIAGNOSIS / STATUS DISPLAY - 14 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 15: Switches/Buttons
Attendance: through a potential free closing-contact (terminals 78/79) the driving over the I-loop 2 can be evaluated STOP-switch (terminals 31/37) Buttons / switches • when pressing the stop switch the gate stops in any desired position. STOP-button (e.g. switch KDT-1N) As stop switch a break contact has to be used. If no stop switch is connected, terminals 31/37 have to be wire-bridged. The stop input has no emergency stop function! - In order to ensure the emergency stop function, provide the supply line with an all-pole disconnecting emergency stop switch, that locks after actuation! - 15 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 16: Safety
Important 12/24V 12/24V NC C NO • if the SYNC-function is needed when connect- ing two photocells LS26 (see notes for photo cells), then the infrared frequency of both transmitter-/receiver pairs the Jumper J have to be adjusted in a different way. - 16 - tousek / EN_ST-80A_04 / 25. 03. 2020... - Page 17 1 receiver 1 24Va.c. 12/24V 12/24V 1 2 3 4 5 12/24V 12/24V Important 1 2 3 4 5 • As the photocell LS 45/2 does not support SYNC- function, the photocell transmitters and receivers have to be mounted on different sides! receiver 2 transmitter 2 - 17 - tousek / EN_ST-80A_04 / 25. 03. 2020...
-
Page 18: G Main Closing Edge (Terminals 50/52)
PHC-Test Safety active: photocell self-test is executed with an opening impulse (switch, button) in gate position „closed“. not active: photocell self-test is not executed. Attention • The photocell self-test can only be deactivated by selecting „not active“. • The deactivation of the self-test function is only permitted if the safety installations correspond to the category 3 ! - 18 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 19: Motor
The impulse is being ignored. Forced closing (only with ST 80VA) Operating logic active: this function causes that a manually released boom goes immediately back to closure. not active: the forced closing is deactivated - 19 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 20: Lamps / Lights
• The barrier can be equipped with a boom lamp kit 24Vd.c.,max. 5W, consisting of 6 lamps. • Note: The kit for round booms (Product No. 13710250) must be connected via a specially dimensioned series resistor (R boom lamp) to the control board ST 80A (see figure), the kit for flat booms (Art.Nr. 13710190) without a resistor. Connection of boom lamp kit •... -
Page 21: Peripherals
0 = Signal contact open, 1= Signal contact closed Magnet for boom fixing • The barrier can be equipped with a magnet 24Vd.c., 5W max. for fixing the boom in closed position. This is connected via a series resistor (R magnet) to the controller ST 80A. Connection of magnet • ATTENTION: turn off power supply! •... -
Page 22: Diagnosis
Time since the last event: hence the end is shown DAYS HOURS : MINUTES : SECONDS $$$$$$$$$$$$$$$$ T -00 00:00:00.0 event type $$$$$$$$$$$$$$$$ Event Status Sensor (control function) Reset / Diagnosis Degree and signal strength of rotation speed sensor is shown on display. - 22 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 23: Induction Loop Detector (Optional)
• Reset: average duration of the key press (> 2s), reset the detector, subsequent initialization of all channels. Insert the board of the induction loop detector on the slot (ISD) of the control board ST 80(V)A STA 11 - 23 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 24: Module Status Display (Optional)
• With the potential free signal contacts K1 (term. 90/91) and K2 (term. 92/93) the barrier status can be evaluated in two ways (see menu point about signal contacts). • Contact load: 24Va.c./d.c., max. 10W - 24 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 25: Inbetriebnahme
$$$$$$$$$$$$$$$$ active confirm $$$$$$$$$$$$$$$$ Photocell $$$$$$$$$$$$$$$$ not active change ? YES $$$$$$$$$$$$$$$$ Main safety edge $$$$$$$$$$$$$$$$ Main safety edge $$$$$$$$$$$$$$$$ $$$$$$$$$$$$$$$$ active confirm $$$$$$$$$$$$$$$$ Main safety edge $$$$$$$$$$$$$$$$ not active - 25 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 26: Erroy Analysis
(= without function in connection with light control board STA 11 traffic light control STA 11) Control relays are switching but no motor is in emergency release (unlo- lock motor gearing barrier movement cked) - 26 - tousek / EN_ST-80A_04 / 25. 03. 2020... -
Page 27: Dimensioned Drawing
8. Dimensioned drawing of housing IP54 ST 80(V)A • Dimensions in mm Depth: 105 We reserve the right to change dimensions and technical specifications without prior notice. - 27 - tousek / EN_ST-80A_04 / 25. 03. 2020... - Page 28 Buitenheide 2A/ 1 Tel. +32/ 11/ 91 61 60 your service partner: Fax +32/ 11/ 96 87 05 info@tousek.be Tousek Sp. z o.o. Poland PL 43-190 Mikołów (k/Katowic) Gliwicka 67 Tel. +48/ 32/ 738 53 65 Fax +48/ 32/ 738 53 66 info@tousek.pl...
