Camera activations can be sent / transmitted instantly to you based on your preferred Send Mode settings.
They are either;
Molnus (default setting) - Uses DATA - Images / Videos (less than 10MP) transmitted to FREE Cloud
1.
Service using GPRS
2.
Phone MMS - Uses AIRTIME - Images transmitted to cell phones (up to 4)
Email MMS - Uses AIRTIME - Images transmitted to e-mail addresses (up to 4) as MMS's
3.
4.
Email GPRS - Uses DATA - Images / Videos (less than 10MP) will be transmitted to e-mail addresses
(up to 4) using GPRS
This Guide will assist you with Phone MMS, Phone Email, Email GPRS...
MG984G-36M
Sending via:
Phone MMS
Email MMS
Email GPRS
CAMERA TRAPS cc
+27(0)83 560 0555 | +27(0)82 422 0356
info@cameratraps.co.za
www.cameratraps.co.za
SOUTH AFRICA
Advertisement
Related Manuals for ScoutGuard MG984G-36M
Summary of Contents for ScoutGuard MG984G-36M
- Page 1 MG984G-36M Sending via: Phone MMS Email MMS Email GPRS CAMERA TRAPS cc +27(0)83 560 0555 | +27(0)82 422 0356 info@cameratraps.co.za www.cameratraps.co.za SOUTH AFRICA Camera activations can be sent / transmitted instantly to you based on your preferred Send Mode settings.
- Page 2 MG984G-36M You can either input your relevant Cellular Network Providers Parameters manually into the camera BMC CONFIG_CAMERA_TRAPScc.exe or you can download the setup application program and save it to your PC / laptop which has all these parameters pre-installed and you can also change the camera settings.
- Page 3 MG984G-36M Phone MMS: Select 'Send To: Phone MMS' and press OK and it will ask you to fill in the relevant cell network providers' URL / IP / Port / APN parameters that are specific to the SIM card you have inserted into the camera.
- Page 4 MG984G-36M Email MMS: Select 'Send To: Email MMS' and press OK and it will ask you to fill in the relevant cell network providers' URL / IP / Port / APN parameters that are specific to the SIM card you have inserted into the camera.
- Page 5 MG984G-36M Email GPRS: Select 'Send To: Email GPRS' and press OK and it will first ask you to fill in the relevant SENDING Email SMTP parameters i.e. of the Email address used to SEND the footage. The same Email address can be used to SEND and RECEIVE footage.
- Page 6 MG984G-36M SETUP USING APPLICATION PROGRAM BMC CONFIG_CAMERA_TRAPScc.exe All the relevant cell network provider / MMS / GPRS parameters AND camera settings can also be set up on your PC and then uploaded to the camera using the setup application program CONFIG_CAMERA_TRAPScc.exe.
- Page 7 MG984G-36M Step 1 Step 3 Step 2 Step 4 Step 5...
- Page 8 MG984G-36M STEP 3: Choose between default or manual settings. For first time use, we suggest using the default settings. STEP Input phone number phone to receive images “administrator number” field email address in “Receive Email 1” field (This is NOT the phone number of the inserted SIM card that resides in the camera). The administrator number...
- Page 9 MG984G-36M REMOTE COMMUNICATION / CONTROL OF YOUR CAMERA Please Set "SMS control" to ON in the second tab from the right in the camera menu to allow this feature. When the camera is switched to the ON mode, you can change / check...
- Page 10 MG984G-36M STEP 5: Operator - Choose the country and provider that corresponds with your SIM card (which is inserted in your camera). A SMS text message will again be created with the relevant settings to send to the camera. Click 'Send'... and it will take you through to the next step...
- Page 11 MG984G-36M Your camera should now be successfully loaded CONTROLLING / CHANGING PARAMETERS REMOTELY: • Select “Control” to remotely set / change camera / user custom settings (Work parameter). Here you are also able to change MMS / network / Email / recipients settings / or set to back default.
- Page 12 MG984G-36M For more settings, select “Advance” to set Super user information, change the password, Format the SD card, System Checking, Arming, or Disarming. On Camera Setup Options To view the camera settings menu, slide the power switch to TEST/SETUP mode and press MENU button on the keypad.
- Page 13 Version 1.3 CAMERA TRAPS cc +27(0)83 560 0555 | +27(0)82 422 0356 info@cameratraps.co.za www.cameratraps.co.za SOUTH AFRICA...
