Magnum Industrial MI-91500 Operating Manual

Hide thumbs Also See for MI-91500:
Table of Contents

Advertisement

Quick Links

MODEL NO.: MI-91500
OPERATING MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MI-91500 and is the answer not in the manual?

Questions and answers

Related Manuals for Magnum Industrial MI-91500

Summary of Contents for Magnum Industrial MI-91500

  • Page 1 MODEL NO.: MI-91500 OPERATING MANUAL...

  • Page 2: Rules For Safe Operation

    RULES for SAFE OPERATION MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW To help ensure safe operation, please take a moment to learn the how to operate the machine and understand its applications and limitations, as well as potential hazards. KMS Tools and Equipment disclaims any real or implied warranty and holds itself harmless for any injury that may result from the improper use of its equipment.

  • Page 3: Tool Overview

    TOOL OVERVIEW MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW MAIN COMPONENTS (A) BLADE TENSION ADJUSTMENT HANDLE (K) MAGNETIC SAFETY SWITCH (B) UPPER WHEEL COVER DOOR LOCK KNOB (L) BLADE TRACKING ADJUSTMENT KNOBS (C) BLADE GUARD (M) BLADE GUARD ADJUSTMENT HANDWHEEL...

  • Page 4: Additional Requirements For Set Up

    ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW • Before you assemble your band saw, review the parts breakdown and keep it ready for reference. • Start by removing the parts from the packaging. • Carefully check the packaging for small pieces before you continue.

  • Page 5: Lifting And Handling The Machine

    ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW WARNING! This saw is heavy. You will need the help of at least one other person or a hoist for the following steps! To limit the risk of serious injury or damage to the machine, any equipment used to lift this...

  • Page 6: Attaching The Table

    MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW ATTACHING THE STORAGE BRACKETS The MI-91500 is equipped with onboard storage brackets to store the rip fence and miter gauge when not in use. Attach the rip fence storage bracket and miter gauge...
  • Page 7 ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW ATTACHING THE TABLE CONTINUED 4. Rotate the table 1/4 turn counterclockwise so that the saw blade is now perpendicular to the TABLE SLOT (F). See Figure 11. Gently lower the table onto the bracket so the LONG BOLTS (C) in the centre of the trunnions pass through the holes in the TABLE-TILT BRACKET (G).
  • Page 8 ASSEMBLY INSTRUCTIONS MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW INSTALLING THE FENCE ASSEMBLY The MI-91500 is equipped with a deluxe T-fence and guide rail system. Follow all assembly and adjustment instructions in the manual supplied in the box with the fence.

  • Page 9: Connecting To A Power Source

    If in doubt, contact a qualified electrician before connecting to the power source. MAGNETIC SAFETY SWITCH The MI-91500 features a MAGNETIC SAFETY SWITCH, which is mounted to the machine’s frame. This magnetic switch is designed to protect the unit and the user from power surges, power outages and unwanted or unintentional start-up.

  • Page 10: Basic Adjustments

    BASIC ADJUSTMENTS MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW WARNING! To avoid injury, ensure the power switch is OFF and the power cord is unplugged before adjusting the band saw. TILTING THE TABLE The table can tilt from 0° to 45° to the right to allow for bevel cutting. To set the table angle refer to the TABLE TILT ANGLE INDICATOR (A) located under the band saw table.
  • Page 11 BASIC ADJUSTMENTS MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW WARNING! To avoid injury, ensure the power switch is OFF and the power cord is unplugged before adjusting the band saw. ADJUSTING THE UPPER AND LOWER BLADE GUIDES The GUIDE BEARINGS (A) keep the blade from moving from side to side during cutting and, to ensure accuracy, must be snug to the blade but not touching it.

  • Page 12: Changing Speed Settings

    WARNING! To avoid injury, ensure the power switch is OFF and the power cord is unplugged before adjusting the band saw. CHANGING SPEED SETTINGS The MI-91500 has two speed settings: 2,300 LFM (low) and 3,250 LFM (high). • Low speed is ideal for cutting soft woods over 4” in height or hardwoods over 2”...

  • Page 13: Adjusting Blade Guard

    BASIC ADJUSTMENTS MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW WARNING! To avoid injury, ensure the power switch is OFF and the power cord is unplugged before adjusting the band saw. ADJUSTING BLADE GUARD The BLADE GUARD (A) can be adjusted to accommodate the height of the workpiece.

  • Page 14: Periodic Maintenance And Lubrication

    MAINTENANCE MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW WARNING! Always disconnect the machine from the power source before performing any lubrication or maintenance. PERIODIC MAINTENANCE and LUBRICATION Lubrication Keep the RACK AND PINION (A), BLADE TENSION ADJUSTMENT SCREW (B), and the TABLE TRUNNION (C) well greased and free of dust and debris.
  • Page 15 110V CHANGED TO 220V MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW WARNING! Always disconnect the machine from the power source before servicing. 1. Use cross screwdriver to loosen the screws and remove the switch plate. 2.Remove the connecting wire of the indicator light by cross screwdriver, and turn the nut on the indicator light counterclockwise;...
  • Page 16 110V CHANGED TO 220V MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW 5.Dismantle the connecting wire on 110V 15A temperature controlled switch and connect on 220V 7A temperature controlled switch; then install at reverse direction by the above steps. 110V 15A temperature...
  • Page 17 110V CHANGED TO 220V MAGNUM INDUSTRIAL MI-91500 DELUXE 14” BAND SAW 8.Push the contactor to the middle through the groove and Aluminum plate. 9.Pull out power cord and fasten the cable retainer. (You can refer to the original indentation of the cable retainer.)
  • Page 19 107 108 109 110 128a 141A 141A-1 141A-2 141A-6 141A-3 141A-4 141A-5...
  • Page 21 PARTS LIST FOR MI-91500 " " " " " 4 " MI-91500-023B " 8 " " " MI-91500-034 DRIVE BELT A-33 MI-91500-038 HEX NUT 5/16 " " " MI-91500-045...
  • Page 22 PARTS LIST FOR MI-91500 PART NO. DESCRIPTION SPECIFICATION MI-91500-046 HEX NUT 3/4" MI-91500-047 BEARING HOUSING MI-91500-048 MI-91500-049 COVER MI-91500-050 HEX SCREW 3/8"-1 1/2 MI-91500-051 HEX SCREW 3/8"-2 1/2" MI-91500-052 MOTOR MI-91500-053 LEVER 3/8"-1" MI-91500-054 MI-91500-055 WASHER 3/8" MI-91500-056 HEX NUT 3/8"...
  • Page 23 PARTS LIST FOR MI-91500 PART NO. DESCRIPTION SPECIFICATION MI-91500-126 BEARING 6200ZZ MI-91500-127 C-RING S-10 MI-91500-128 BEARING SHAFT MI-91500-128A BEARING LONG SHAFT MI-91500-129 BEARING MOUNT MI-91500-130 CAP SCREW 1/4-3/4" " MI-91500-131 GUARD POST MI-91500-132 POINTER MI-91500-133 PHILLIPS HD. SCREW 3/16 -1/2" "...
  • Page 24 PARTS LIST FOR MI-91500 PART NO. DESCRIPTION SPECIFICATION MI-91500-F14 CAP SCREW MI-91500-F15 L TYPE PLATE MI-91500-F16 KNOB 5/16*5/8" MI-91500-F19 POINTER MI-91500-F20 HEX BOLT 1/4*3/4" MI-91500-F21 RUNNER MI-91500-F22 BEARING SHAFT MI-91500-F23 LOCK MECHANISM MI-91500-F24 HEX NUT MI-91500-F25 FENCE HANDLE MI-91500-F26 REAR RAIL...
