- Page 1 How to Get a BL67-GW-EN Gateway to Communicate with a Unitronics Touch Screen Display G1005 Revised 1/14/2014...
-
Page 2: About This Guide
ABOUT THIS GUIDE This “How to” will show the user how to connect a BL67-GW-EN to a Unitronics touch screen display. Hardware • BL 67-GW-EN, Set Rotary Switches to 000 • BL67-B-2M12-P (Slice housing) • BL67-4DI4DO –PD (Slice) • Appropriate Power cable for the BL67 •... - Page 3 Hook up the station in the same configuration show in the below photo. Note that RJ 45 (A) goes from the Ethernet Switch to the Unitronics Touch Screen Display. www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441...
-
Page 4: Software Configuration
SOFTWARE CONFIGURATION -> Open BL67-GW-EN VisLogic example program -> Wait for the VisLogic software to open www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441... - Page 5 -> Connection -> Communications -> Check to make sure the correct RS 232 COM Port is selected -> Click “Get OPLC Information” www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441...
- Page 6 -> Verify “OPLC Information” pops up -> Click Exit -> Connection -> Download -> Stop – Download - Reset www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441...
- Page 7 -> No ->Yes www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441...
- Page 8 -> Press “Activate” on the touch screen -> Notice that the status changes to “Connected” -> Trigger the sensor and then press “Read” -> Notice that the “Read” bit is now high www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441...
- Page 9 -> Remove the trigger from the sensor; press “Read” again -> Notice the “Read” bit is now low -> Press the “write” data on the touch screen www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441...
- Page 10 -> Press “1” -> Press “enter” -> Notice that the write value changed to “1” www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441...
- Page 11 -> Also notice on the BL67-4DI4DO-PD slice that bit “4” has turned on -> Press “Close” to disconnect the touch screen from the computer www.turck.com • 1-800-544-7769 • Fax: (763) 553-0708 • TURCK • Minneapolis, MN 55441...
