- Page 1 SR100 SR100 - (AS05190) Centralina di controllo ISTRUZIONI PER L’INSTALLAZIONE Control unit INSTRUCTIONS FOR INSTALLATIONS...
- Page 2 SR100 Grazie per avere scelto GIBIDI. LEGGERE ATTENTAMENTE QUESTO MANUALE PRIMA DI PROCEDERE ALL’INSTALLAZIONE. AVVERTENZE: Questo prodotto è stato collaudato in GI.BI.DI. verificando la perfetta corrispondenza delle caratteristiche alle direttive vigenti. GI.BI.DI. S.r.l. si riserva la facoltà di modificare i dati tecnici senza avviso, in funzione dell’evoluzione del prodotto. SMALTIMENTO: GI.BI.DI.
- Page 3 SR100 027G1 DIP1 DIP2 START 10 11 12 13 14 15 16 17 18...
-
Page 4: Installation Warnings
SR100 SR100 / AS05190 Control unit Electronic control unit for the automation Type of a shutter motor Power supply 230Vac monophase 50/60 Hz N° motors 230 Vac Motor power supply Flashing light 230Vac 25W max Accessories power supply 24Vdc 1,2W max Functioning time 125 s max Pause time... -
Page 5: Warnings For The User
SR100 • Mark the automated gate with visible warning plates. • Warn the user that children and animals may not play or stand around near the gate. • Appropriately protect the dangerous points (for example, use a sensitive frame). WARNINGS FOR THE USER In the event of an operating fault or failure, cut the power upstream of the control unit and call Technical Service. -
Page 6: Protection Fuses
SR100 PROTECTION FUSES Position Value Type Description Accessories power supply input protection 500 mA RAPIDO Board protection on 230 Vac power supply input RAPIDO FUNCTIONS PROGRAMMING ( DIP SWITCH DIP1) The settings are memorized during the pause phase (door closed). Status Function Description... -
Page 7: Default Settings
SR100 Status Function Description DIP 6 Channel 1 of the transmitter works as START. DIP 7 DIP 6 Channel 2 of the transmitter works as START. DIP 7 RADIO CHANNELS DIP 6 SETTING Channel 3 of the transmitter works as START. DIP 7 DIP 6 Channel 4 of the transmitter works as START. -
Page 8: Signalling Leds
SR100 FUNCTIONS SETTING ( DIP SWITCH DIP2) Settings are memorized when the door is closed. Status Function Description Disables PHOTO input DIP1 PHOTOCELL PHOTO input enabled Disables SAF input set as STOP with NC contact DIP 2 STOP NC Enables SAF input set as STOP with NC contact. Enables 8K2 edge reading DEFAULT SETTINGS DIP1... -
Page 9: Configuration Jumper
SR100 CONFIGURATION JUMPER SW11 Functioning Configuration Description mode Standard rolling code functioning with variable code OPEN HCS ROLLING C - B HCS FIX Rolling code functioning with fixed code manageable with PRG_01 Consolle A - C DIP SWITCH Fixed code functioning with dip switch SW12 Functioning Configuration... - Page 10 SR100 CE Declaration of conformity The manufacturer: GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B, 46025 Poggio Rusco (MN) ITALY Declares that the products: ELECTRONIC CONTROL UNIT SR100 are in conformity with the following CEE Directives: • LVD Directive 2006/95/CE and subsequent amendments; •...
- Page 11 GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: comm@gibidi.com Numero Verde: 800.290156 w w w . g i b i d i . c o m...
