Summary of Contents for Bandini Industrie GiBiDi BA230
Page 1
BA230 BA230 - (AS05550) Apparecchiatura elettronica ISTRUZIONI PER L’INSTALLAZIONE Electronic control unit INSTRUCTIONS FOR INSTALLATIONS...
Page 2
BA230 • Questo prodotto è stato collaudato in GI.BI.DI. verificando la perfetta corrispondenza delle caratteristiche alle direttive vigenti. • La GI.BI.DI. S.r.l. si riserva la facoltà di modificare i dati tecnici senza avviso, in funzione dell'evoluzione del prodotto. LEGGERE ATTENTAMENTE QUESTO MANUALE PRIMA DI PROCEDERE ALL’INSTALLAZIONE. •...
Page 3
BA230 LCD1 BA230 G:B:D:021G1 LED STATUS 9 9 2 9 9 3...
Page 4
BA230 BA230 / AS05550 Control unit Electronic control unit for the automation of one or two 230V motors for swinging and sliding gates, Type overhead doors and barriers Power supply 230Vac monophase 50/60 Hz N° motors 1 or 2 Motor power supply 230Vac Flashing light 230Vac 40W max...
BA230 • Management of courtesy light with 12 Vdc or 230 Vac output. • Possibility to program: automatic closing, fast closing, pre-flashing, hammer stroke, final closing and opening stroke, courtesy light, ending movement additional time, flashing light (both flashing and fixed), external clock management with three different modes, number of cycles for scheduled maintenance, installer code and number of performed cycles.
BA230 Limit switch input opens motor 2 (N.C.). FCAM2 If not used, disable during the programming phase. Limit switch input closes motor 2 (N.C.). FCCM2 If not used, disable during the programming phase. PHOTOCELL 2 input (N.C.). If not used, disable during the programming phase. Operation: Input enabled during both opening and closing.
Page 8
BA230 PROGRAMMING PROCEDURE AND SYSTEM CONFIGURATION The system adjustments can be accessed via the display. There are 5 different menus marked with the letters A, C, F , H and E. To enter the programming procedure, start from the display as shown in the picture and press simultaneously the keys ESC and OK for 3 s (The writing Gbd will turn off) Go to step 2.
BA230 The last figure is flashing. With the + or – keys, the user selects the fourth digit of the installer 4 6 8 0 code. When the required digit is selected, press OK to confirm and go to step. Now the installer code is complete: if it is correct, go to step 8.
Page 10
BA230 MENU C When the 5 main menus are shown on the display (letters A C F H E) and the letter C is blinking. A C F H E Press OK to enter the selected menu (in the example, menu C). Use the + or –...
Page 11
BA230 The third digit blinks. 0 1 0 0 Use the + and – keys to modify the value of this digit. Press OK to confirm and go to step 18. The fourth digit blinks. 0 1 5 0 Use the + and – keys to modify the value of this digit. Press OK to confirm and go to step 19.
Page 12
BA230 E3 = SAFETY DEVICE (EDGE) Press OK in sequence to: Enable the input (the Y will appear next to E3) Disable the input (the N will appear next to E3) Use the + and – keys to enter the following or the previous menu. Press ESC to leave the menu;...
Page 13
BA230 It configures the system for 2 motors. In the menu C11 it will be possible to set the courtesy light output: surrendering the electric lock 2 N = courtesy light disabled Y1 = courtesy light disabled 2 MOTORS CONFIGURATION Y2 = courtesy light on ELECTRIC LOCK 2 output (see diagram 12 Vdc output) The courtesy light output is 3-minutes timed.
BA230 The opening and closing movement in the dead man's mode stops always on the first limit switch. The possible regulations are: PHASE SHIFT IN OPENING - PHASE DEAD MAN LOGIC SHIFT IN CLOSING. The enabling of this menu automatically disables A6-A7-A8. MENU C: FUNCTIONS SELECTIONS KEY + enters the following menu C1-C2-C3-…...
BA230 The exclusion of SAFETY DEVICE by mean of the menu E3 excludes the safety edge test. PHASE 2: if the edge with N.C. contact is enabled, when the Start or Pedestrian command is given, the power to the safety devices is cut off for 0,5 s and then restored: : if the inputs of the safety devices open and immediately return NC, the motors start, otherwise a fault is signalled with 3 long flashes (2 sec.) of the flashing light.
Page 16
BA230 If decelerations are enabled, the pulse is given at the end of the deceleration time. FINAL STROKE IN OPENING The final stroke is not managed by the safety devices. AND CLOSING Disabled with sliding configuration and with dead man logic Disables the closing final stroke function.
Page 17
BA230 Enables the RESERVE input for the connection of an external watch Operation: If the contact on the RESERVE input is closed, following a START command the door opens but does not close automatically. When the EXTERNAL WATCH, contact closes, after the pause time the door will close automatically. CLOSING NOT ALLOWED Closing cannot be started with a START command.
BA230 Adjusts motor 1 thrust during deceleration phase. MOTOR 1 DECELERATION 0001 = minimum force. SPEED 1 0010 =maximum force. Adjusts motor 2 thrust. MOTOR 2 FORCE 0001 = minimum force. 0010 =maximum force. Adjusts motor 2 thrust during deceleration phase. MOTOR 2 DECELERATION 0001 = minimum force.
Page 19
BA230 MENU E: EXTERNAL DEVICES ENABLING-DISABLING KEY + enters the following menu E1-E2-E3 KEY – enters the previous menu E3-E2-E1 KEY OK enables Y (yes). Enables the function. KEY OK enables N (no). Disables the function. KEY ESC leaves the menu. WARNING: The STOP key cannot be excluded in menu E.
Page 20
BA230 • When leaf 1 arrives at the desired opening position START leaf 1 stops • When leaf 2 arrives at the desired opening position START leaf 2 stops • Counting of the pause time in opening starts • When the desired pause time has elapsed START leaf 2 starts closing Leaf 1 starts closing.
BA230 4 fast flashings Blocked closed door Photo 1 test failed at opening 4 fast flashings Blocked open door Photo 1 test failed at closing 4 slow flashings Blocked closed door TRIAC test failed at opening 4 slow flashings Blocked open door TRIAC test failed at closing Blocked closed door 3 slow flashings...
BA230 MOTOR 1 DECELERATION MOTOR 2 FORCE MOTOR 2 DECELERATION • Parameters type H: MOTOR 1 OPENING TIME MOTOR 1 CLOSING TIME MOTOR 1 DECELERATION TIME MOTOR 2 OPENING TIME MOTOR 2 CLOSING TIME MOTOR 2 DECELERATION TIME LEAF 2 PHASE SHIFT IN OPENING LEAF 1 PHASE SHIFT IN CLOSING PAUSE TIME PEDESTRIAN OPENING TIME...
BA230 BA230 DISPOSAL Gi.Bi.Di advises recycling the plastic components and to dispose of them at special authorised centres for electronic components thus protecting the environment from polluting substances. SIMPLIFIED PROGRAMMING Connect all the connections (wire motors using a 1,5 mm² wire) Enter the installation code, and then set the type of function desired from menu A2/A3.
Page 24
BA230 CE Declaration of conformity The manufacturer: GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B, 46025 Poggio Rusco (MN) ITALY Declares that the products: ELECTRONIC CONTROL UNIT BA230 are in conformity with the following CEE Directives: • LVD Directive 2006/95/CE and subsequent amendments; •...
Page 25
GI.BI.DI. S.r.l. Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: comm@gibidi.com Numero Verde: 800.290156 w w w . g i b i d i . c o m...
