P411W-32P PCIe 4.0 User Guide
Table 5 Mixed Drive-to-Port Connection Example
Adapter Label Tool Mapping Port Number
C0 C0.1
C0.0

7 Cable Support

Broadcom supports the following cables for use with the adapter.
Table 6 Supported NVMe Switch Adapter Cables
MPN
05-60001-00 x8 8654 to 2x4 8612, AltWiring 1M
05-60002-00 x8 8654 to 2x4 8643 (W), SMC 1M
05-60004-00 x8 8654 to 2x4 8654, 9402 1M
05-60005-00 x8 8654 to 2xU.2 Direct, 1M
05-60006-00 x8 8654 to 8xU.3 Direct 1M
05-60007-00 x8 8654 to 1x8 8654, 9402 1M

8 P411W-32P NVMe Switch Adapter Characteristics

8.1 LEDs

The adapter has one heartbeat LED and one system error status LED. The LED blinks at 1 Hz to indicate that the firmware
on the board is operational. The system error status LED is lit when a system error occurs.

8.2 Physical Characteristics

The adapter is a 6.127 in. × 2.712 in. (155.65 mm × 68.90 mm) board. The component height on the top and bottom of the
adapter complies with the PCI Express Card Electromechanical Specification Revision 3.0. The following figure shows the
adapter board layout.
Broadcom
Drive
0 x2
2 x2
4 x1
5 x1
6 x1
7 x1
Cable Description Adapter Connector
1 x8 SFF-8654 Slimline
1 x8 SFF-8654 Slimline
1 x8 SFF-8654 Slimline
1 x8 SFF-8654 Slimline
1 x8 SFF-8654 Slimline
1 x8 SFF-8654 Slimline
NVMe Switch Adapter
Backplane Connector
Two x4 SFF-8612 OCuLink
Two x4 SFF-8643 Mini-SAS HD
Two x4 SFF-8654 Slimline
Two U.2 SFF-8639
Eight U.3 SFF-8639
One x8 SFF-8654 (SlimSAS)
P411W-32P-UG104
