S16 Unit Characteristics (460V) - nVent Hoffman SpectraCool Slim Fit Instruction Manual

UNIT
CATALOG NUMBER
Indoor Model without Communications Board (°C Controller)
Indoor Model with Communications Board (°C Controller)
Indoor Model without Communications Board (°F Controller)
Indoor Model with Communications Board (°F Controller)
COOLING PERFORMANCE
Total L35 L35, 50Hz, according to DIN EN 14511 (Watt)
Cooling performance L35 L35 (Watt) 50/60Hz
Cooling performance L35 L50 (Watt) 50/60Hz
Refrigerant
Refrigerant Charge (g)
Max. allowable operating pressure (p. max.) bar
Operating Temperature Range (Min/Max °C)
Operating Temperature Range (Min/Max °F)
Setting Temperature Range (Min. / Max. °C Controller)
Setting Temperature Range (Min. / Max. °F Controller)
����� 0 Static Pressure:
Internal loop (m³/h)
External loop (m³/h)
Duty Cycle
ELECTRICAL DATA
Rated Voltage (Volt)
Phase
Frequency (Hz)
Operating Range
Max power Consumption 50/60Hz L35 L35 (Watt)
Max power Consumption 50/60Hz L35 L50 (Watt)
Max. Nominal Current (Amps)
Starting Current (Amps)
Pre-fuse T (Amps)
Agency Approvals
Power Input Description
PERFORMANCE FACTOR (EER), 50Hz, DIN EN 14511
Cooling Performance L35 / L35
Cooling Performance L35 / L50
ENCLOSURE PROTECTION
IP Code (External loop / Internal loop)
CONTROLLER
Description
Controller Location
Factory Default Setpoint (°C Controller)
Factory Default Setpoint (°F Controller)
SOUND LEVEL
At 1 M (dBA)
UNIT CONSTRUCTION
Material
Finish
UNIT DIMENSIONS
Height (mm)
Width (mm)
Depth (mm)
Weight (kg)
C-NET INDUSTRIAL LTD. | +44(0)121 544 8608 | INFO@CNET-IS.CO.UK | WWW.CNET-IS.CO.UK
89116616

S16 UNIT CHARACTERISTICS (460V)

2000W 460V 2500W 460V
S162046G031 S162546G031
S162046G041 S162546G041
S162046G050 S162546G050
S162046G060 S162546G060
2200 2680
2200 / 2400 2680 / 2800
1820 / 1900 2200 / 2300
R134a R134a
709 850
28 28
10 / 55 10 / 55
50 / 131 50 / 131
20 / 55 20 / 55
72 / 120 72 / 120
454 / 484 447 / 466
634 / 654 1104 / 1143
100% 100%
400 / 460 400 / 460
3~ 3~
50/60 50/60
+/- 10% +/- 10%
900 / 1180 1150 / 1510
1060 / 1340 1330 / 1770
2.2 / 2.6 3.2 / 3.4
7 / 9 11 / 11
15 15
UL-listed, cUL-listed, EA C, CE
Terminal Block
2.44 / 2.03 2.33 / 1.85
1.72 / 1.42 1.65 / 1.30
IP34 / IP54 IP34 / IP54
Smart controller with display
Ambient side
35 35
80 80
70 72
Steel
RAL 7035
1580 1580
400 400
295 295
68 70
4000W 460V
S164046G031
S164046G041
S164046G050
S164046G060
4000
4000 / 4500
3050 / 3450
R134a
1247
28
10 / 55
50 / 131
20 / 55
72 / 120
494 / 576
1070 / 1184
100%
400 / 460
3~
50/60
+/- 10%
1790 / 2310
1850 / 2430
4.2 / 4.4
14 / 15
15
2.23 / 1.95
1.65 / 1.42
IP34 / IP54
35
80
72
1580
500
340
92
- 61 -
