TABLE OF CONTENTS Warranty and Return Policy ..................................2 General Safety Instructions ..................................3 Receiving The Air Conditioner..................................3 Handling And Testing The Air Conditioner ..............................3 Installation Instructions ....................................4 Dimension Drawings ....................................4 Mounting Cutout Dimension ..................................5 Wire Diagrams And Schematics ..................................
GENERAL SAFETY INSTRUCTIONS Observe the following general safety instructions for installation and operation of this product: • This appliance is for installation only in locations not accessible to the general public. • This appliance is not intended for use by persons, including children, with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
INSTALLATION INSTRUCTIONS 1. Inspect air conditioner and verify functionality before mounting the air conditioner, see HANDLING AND TESTING THE AIR CONDITIONER on page 3. 2. Using the cutout dimensions shown in this manual, prepare the air “IN” and air “OUT” openings, and mounting bolt hole pattern for the enclosure.
5.00 WIRE DIAGRAM, 230 V, LEVEL 1, 4000 BTU 3.50 89111007 REV D SCHEMATIC, 230 V, LEVEL 1, 4000 BTU PART NO. 89111007 SEE NOTES MATERIAL FINISH NONE TOLERANCE UNLESS NOTED PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF PENTAIR EQUIPMENT PROTECTION.
SCHEMATIC, 115 V, LEVEL II AND III, 4000 BTU 4.25 WIRE DIAGRAM, 230 V, LEVEL II AND III, 4000 BTU PART NO. MATERIAL FINISH 5.00 TOLERANCE ONE PLACE ( TWO PLACE THREE PLACE ANGLES PROPRIETARY AND CONFIDENTIAL SolidW THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF HOFFMAN ENCLOSURES.
5.00 SCHEMATIC, 460 V LEVEL I, 4000 BTU 3.50 50/60 HZ WIRE DIAGRAM 89111009 REV E 5.00 SCHEMATIC, 460 V LEVEL II AND III, 4000 BTU PART NO. 89111009 MATERIAL SEE NOTES FINISH NONE UNLESS OTHERWISE SPECIFIED DIMENSIONS AND TOLERANCES IN INCH TOLERANCES: ONE PLACE DECIMAL TWO PLACE DECIMAL...
PARTS LIST Part Description Part No. Condenser Coil 29412010SP Filter, drier, refrigerant 52602800SP ITEM NO. PART NUMBER DESCRIPTION QTY. 10-1106-14 TSTAT LEVEL II III Compressor See Components List 10-1005-21 RELAY, PWR, COIL: 24VDC, DPNO 10-1006-94 TRANS, CNTL 120-24V,20VA Hot Gas bypass valve (CR2904xx units only) 89100261SP 086912 TBLK, 18 STATION AC 1425...
TECHNICAL INFORMATION DESIGN DATA BTU/Hr @ MOPD Full Load Max Ambient Shipping Model Voltage Phase Max Ambient Amps Cooling Amps Temperature °F/°C Weight lb/kg Temperature °F/°C CR290216GXXX 50/60 9.2/7.8 2600/3000 131/55 98/44 CR290226GXXX 50/60 3.7/3.6 2600/2700 131/55 98/44 CR290246GXXX 50/60 2.0/1.9 2600/2700 131/55...
MAINTENANCE Performing preventative maintenance (PM) helps to keep your nVent HOFFMAN AC unit operating at the highest most efficient levels. Maintenance should be performed at least twice a year, more frequently when in challenging conditions, such as dusty, high humidity, high heat, oily or corrosive environments.
Cleaning Instructions: 1. Flush the filter with warm water from the exhaust side to the intake side. DO NOT USE CAUSTICS. 2. After flushing, allow filter to drain. Placing it with a corner down will assure complete drainage. 3. Recoat the filters with RP Super Filter Coat adhesive. When spraying filter do so from both sides for maximum concentration of adhesive.
PREVENTATIVE MAINTENANCE/INSPECTION Maintenance/Inspection Recommendations Last Completed (Perform at least 2 times per year – more frequently as required by operational environment) Check Point Description Date Date Date Date Run unit through all modes of operation and record temperatures, Operational Inspection voltages, and amperes Comments: Visually inspect unit for damage, cleanliness, missing, loose, or...
TROUBLE SHOOTING "Unit won't Cool" w/ Manual Possible low charge. Verify pressures, contact Replace fan. Tstat 115V/230V/460V HVAC certified Technician. Correct voltage and retest. Does the unit have Is the fan Is there correct correct supply voltage? Contact certified electrician. running? voltage to the fan? Is the internal temp...
Page 20
CR29 Compressor wont start (Unit w/ Manual Tstat) Is the enclosure is Compressor Replace Compressor Is the thermal temp 10 ⁰F above Relay/Start relay Relay / Start Relay overload closed? set point. energized? Adjust Tstat setting (turn Replace thermal Check capacitor(s) clockwise) to call for cooling.
Page 21
Evaporator Coils Freezing (Unit w/ Manual Tstat) Possible Causes: – Electrical connections – Bad fan Is voltage to inoperable fan Is the fan running? Possible Causes: correct? – Faulty electrica connections for fan. Is the enclosure Replace seals and gaskets properly sealed on enclosure.
Page 22
Unit Tripping Breaker (Controller or Manual Tstat) Does breaker trip Check power connections and instantaneosly? components for possible short circuit. Verify correct power supply. Is the compressor Does breaker trip when Replace Compressor shorted to ground? Compressor comes on? Check electrical Check electrical Are fuse and breaker the correct connections and...
