TABLE OF CONTENTS Warranty And Return Policy ..................................2 General Safety Instructions ..................................3 Receiving The Air Conditioner ..................................3 Handling And Testing The Air Conditioner ..............................3 Installation Instructions ....................................4 Dimension Drawings ....................................4 Mounting Cutout Dimension ..................................5 Wire Diagrams And Schematics ...................................6 N16 with Mechanical Thermostat Wire Diagram ..............................6 N16 with Mechanical Thermostat Schematic ..............................
GENERAL SAFETY INSTRUCTIONS Observe the following general safety instructions for installation and operation of this product: • This appliance is for installation only in locations not accessible to the general public. • This appliance is not intended for use by persons, including children, with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
INSTALLATION INSTRUCTIONS 1. Inspect the air conditioner and verify correct functionality before mounting the air conditioner. See HANDLING AND TESTING THE AIR CONDITIONER on page 3. 2. Using the cutout dimensions shown page 5 in this manual, prepare the air “IN” and air “OUT” openings, and mounting bolt hole pattern for the enclosure.
PARTS LIST Part Description Part No. Filter, Air, Reusable 89057626SP Compressor See Components List Capacitor, Compressor See Components List Coil, Evaporator 15100103SP PART NUMBER DESCRIPTION QTY. Fan, Evaporator See Components List 89057626 FLTR AIR 5.74 X 7.25 W/GLUE 10-1016-82 COMP,ROT,R134A115VXB357RGU Fan, Condenser See Components List 52-6032-09...
TECHNICAL INFORMATION Design Data BTU/Hr @ MOPD Full Load Max Ambient Shipping Model Voltage Phase Max Ambient Amps Cooling Amps Temperature °F/°C Weight lb/kg Temperature N160116GXXX 131/55 27/12.3 N160116GXXX 125/52 27/12.3 N160126GXXX 131/55 27/12.3 N160126GXXX 125/52 27/12.3 Note: XXX will be replaced with a three-digit number designating all desired options. Consult the factory for specific model numbers. TEMPERATURE CONTROL FOR MECHANICAL THERMOSTAT UNIT Note: For Remote Digital Controller Unit, see instruction manual included with Remote Digital Controller Box.
MAINTENANCE Performing preventative maintenance (PM) helps to keep your nVent HOFFMAN AC unit operating at the highest most efficient levels. Maintenance should be performed at least twice a year, more frequently when in challenging conditions, such as dusty, high humidity, high heat, oily or corrosive environments.
Inlet air filter Proper maintenance of the inlet air filter, located behind the front cover, will assure normal operation of the air conditioner. If filter maintenance is delayed or ignored, the maximum ambient temperatures under which the unit is designed to operate will be decreased. If the compressor’s operating temperature increases above designed conditions due to a dirty or clogged filter (or plugged condenser coil), the air conditioner’s compressor will stop operating due to actuation of the thermal overload cut-out switch located on the compressor housing.
CONDENSER AND EVAPORATOR AIR MOVERS Fan and impeller motors require no maintenance. All bearings, shafts, etc. are lubricated during manufacturing for the life of the motor. CAUTION Operation of the air conditioner in areas containing airborne caustics or chemicals can rapidly deteriorate filters, condenser coils, blowers and motors, etc.
PREVENTATIVE MAINTENANCE/INSPECTION Maintenance/Inspection Recommendations Last Completed (Perform at least 2 times per year – more frequently as required by operational environment) Check Point Description Date Date Date Date Run unit through all modes of operation and record temperatures, Operational Inspection voltages, and amperes Comments: Visually inspect unit for damage, cleanliness, missing, loose, or...
TROUBLE SHOOTING Compressor won’t start (Unit w/ Manual Tstat) Possible Causes: Replace capacitor(s) - Bad Cooling If applicable: Check Is the enclosure temp Do you have voltage Contactor/Relay capacitor(s) for 10°F above set point. at compressor? - Loose Wiring proper capacitance. Is cooling contactor/ or connections relay closing?
Page 18
“Unit won’t Cool” w/ Manual Tstat 115 V/230 V/460 V Does the unit have correct Correct voltage and retest.OR supply voltage? Contact certified electrician. Clean and re-test 115 V/ 460 V 260 V Contact Is the phase Is the Verify filter Is the Does Technical...
Page 19
Evaporator Coils Freezing (Unit w/ Manual Tstat) Possible Causes: - Electrical Possible Causes: connections Are the evaporator Is there - Faulty electrical connections for one or both fans. - Bad fan and condenser voltage to the Condenser Fan: fan(s) running? inoperable fan? - Bad HPC (if equipped) Does the capacitor...
Page 20
Unit Tripping Breaker (Controller or Manual Tstat) Check power connections and Does breaker components for possible short circuit. trip instantaneosly? Verify correct power supply. Is the compressor shorted Does breaker trip when Replace Compressor to ground? Compressor comes on? Are fuse/breaker the correct type Check electrical connections and component amp draw.
