S10 COMPONENTS (3 PHASE)

Item Model Series
Part Descriptions
2 Capacitor, Condenser Blower
3 Capacitor, Evaporator Blower
4 Coil, Condenser
5 Coil, Evaporator
6 Communication Board (optional)
7 Compressor
8 Contactor Compressor
Smart Controller °C
9
Smart Controller °F
10 Drain Tube Kit (optional)
11 Filter Air, Reusable (optional)
12 Filter/Dryer
13 Impeller, Condenser
14 Impeller, Evaporator
15 Thermal Expansion Valve
16 Thermal Overload, Compressor
17 Thermistor
18 Transformer, 24V
19 Transformer,460/230V
20 Fuse (Controller)
Accessories
21 Installation Kit
22 Unit Mounting Gasket
23 Mounting standoffs
Structural Parts
24 Louvered Grill Panel
25 Controller Bezel Panel
26 Panel Strike Clip (Pkg. 4)
27 Body Catch Clip (Pkg. 4)
28 Body Front Shell
29 Relay, Overload
30 Relay, Phase Monitor
1500W 460V
Part Numbers
52603214SP
52603214SP
89108399SP
89102609SP
89109039SP
89107888SP
89107296SP
89123540SP
90272220SP
101027177SP
89106977SP
52602800SP
89107375SP
101091122SP
89063955SP
90238425SP
89075654SP (2)
10100693SP
101006128SP
89085114SP
90221633QDSP
90241618SP
89105489SP (4)
89105410SP (2)
89105411SP
90245472SP
89105486SP
89102598SP
89098323SP
89097986SP
89116616
