Measure 1-Port Cable Loss (CAT Mode)
Required Equipment:
LOAD with correct connector type and gender to
-
terminate the end of the DUT.
Optional phase stable jumper cable or adapter to
-
connect the beginning of the DUT to the FieldFox.
1. Press Preset then
2. Select Mode then
3. Then Measure 1
More
4. Then
5. Connect the DUT.
6. Press Freq/Dist and enter
7. Connect the DUT (cable to be tested) to the FieldFox
and connect a LOAD at the end of the DUT.
8. Press Trace 6 then
Data->Mem.
9. Remove the LOAD and leave the end of the DUT
open.
Data Math
10. Press
for high-loss measurements. Press BW 2 then
Averaging
11. Read Avg Cable Loss on the FieldFox screen.
Preset
CAT
Cable Loss (1-Port)
then
Math and
Data –
then
(Cable and Antenna Test)
Start
and
Memory, then
Mem. Use Averaging
4
Stop
frequency.
