Alarm History at the HDSL2 Interface

Figure 18 and Figure 19
H2TU-C HDSL2 interface, respectively. Current alarms are shown in reverse video. The types of alarms reported
for the H2TU-R are described in
Monitor Performance
------------------------------------------------------------------------------
Alarm First
LOSW 03/16/00 00:00
MAL
LA
HBER 03/16/00 00:37
------------------------------------------------------------------------------
Press <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx--xxxx
Monitor Performance
------------------------------------------------------------------------------
Alarm First
LOSW 04/10/00 00:00
MAL
LA
HBER 04/10/00 00:37
SHORT
GND
OPEN
------------------------------------------------------------------------------
Press <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx--xxxx
H2TU-R-402
are examples of Alarm History screens for the H2TU-R HDSL2 interface and the
Table 8 on page 22.
Event Log Config
H2TU-R HDSL2 Alarm History
Last
04/15/00 00:45
04/15/00 00:45
Press: C(l)ear Alarm History
Interface
Statistics :
04/15/00 12:30:01
Figure 18. H2TU-R HDSL2 Alarm History Screen
Event Log Config
H2TU-C HDSL2 Alarm History
Last
04/15/00 00:45
04/10/00 00:45
Press: C(l)ear Alarm History
Interface
Statistics :
04/15/00 12:30:01
Figure 19. H2TU-C HDSL2 Alarm History Screen
