GB.TBLZ09.141001
To install the TBLZ-1-10-09 Cover holder
GOLD/SILVER C, sizes 04-08
1. Application
Upper inspection cover
Cover holder
Holder for the upper inspection cover of the size 04-08
GOLD/SILVER C units installed vertically. The kit contains 2
cover holders for installation in pairs.
2. Function
Mechanical holder with automatic locking device for 10
different angles of aperture.
When the cover is completely open, the locking device
releases automatically.
The cover must be closed completely in order to reengage
the locking function. You can lower the cover one open-
ing position at a time by pressing in the locking devices by
hand.
www.swegon.se
1
Swegon reserves the right to alter specifications.

Advertisement

loading
Need help?

Need help?

Do you have a question about the TBLZ-1-10-09 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Swegon TBLZ-1-10-09

  • Page 1 GB.TBLZ09.141001 To install the TBLZ-1-10-09 Cover holder GOLD/SILVER C, sizes 04-08 1. Application Upper inspection cover Cover holder Holder for the upper inspection cover of the size 04-08 GOLD/SILVER C units installed vertically. The kit contains 2 cover holders for installation in pairs.
  • Page 2 Inspection M8x20 screw side Inner anchor plate Blind rivet Outer edge Outer anchor plate Fig. 3 Outer anchor plate Cover holder arm Washer Washer M8x20 screw M8x20 screw Inner anchor plate www.swegon.se Swegon reserves the right to alter specifications.
