AJAX FireProtect User Manual page 3

necessary to reach 60°С), the detector registers temperature increase, which
triggers a re alarm.
FireProtectPlus has an additional sensor to detect a dangerous CO level. If the
concentration of CO in the air exceeds a certain level, the detector generates an
alarm.
The detector is triggered:
within 60–90 min at carbon oxide concentration 50 ppm / 0.005%
within 10–40 min at CO concentration 100 ppm / 0.01%
within 3 min at carbon oxide concentration 300 ppm / 0.03%.
In case of alarm, the detector activates the built-in buzzer (the siren sound can
be heard from afar) and blinks with the light indicator. When connected to a
security system, both the user and the security company are noti ed of the
alarm.
The siren can be turned off by pressing the touch button (the center of the light
indicator) or in the Ajax app. If smoke and temperature levels do not restore to
normal values, in 10 minutes, the detector turns on the siren again.
Connecting the Detector to the Ajax Security System
Connecting to the hub
Before starting connection:
1. Following the hub user guide, install the
the hub, and create at least one room.
2. Switch on the hub and check the internet connection (via Ethernet cable
and/or GSM network).
3. Make sure that the hub is disarmed and does not update by checking its
status in the Ajax app.
Ajax app . Create the account, add
