USB-1208HS User's Guide

Mechanical

Parameter
Dimensions (L × W × H)
Screw terminal connector and pinout
Parameter
Connector type
Wire gauge range
Pin Signal name
1 AIN0
2 AGND
3 AIN1
4 AGND
5 AIN2
6 AGND
7 AIN3
8 AGND
9 AIN4
10 AGND
11 AIN5
12 AGND
13 AIN6
14 AGND
15 AIN7
16 AGND
17 empty
18 +5V
19 GND
20 DIO0
21 DIO1
22 DIO2
23 DIO3
24 DIO4
25 DIO5
26 DIO6
27 DIO7
28 GND
Table 14. Mechanical specifications
Specification
5.00 × 3.53 × 1.40 in. (127 × 89.9 × 35.6 mm)
Table 15. Connector specifications
Specification
Screw terminal
16 AWG to 30 AWG
Table 16. Single-ended mode pinout
Pin Signal name
29 NC
30 NC
31 AGND
32 NC
33 NC
34 AGND
35 AICKI
36 AICKO
37 NC
38 NC
39 TRIG
40 GND
41 CTR0
42 CTR1
43 TMR
44 GND
45 empty
46 +5V
47 GND
48 DIO8
49 DIO9
50 DIO10
51 DIO11
52 DIO12
53 DIO13
54 DIO14
55 DIO15
56 GND
21
Specifications
