Bay Tek Games TOWER OF TICKETS Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TOWER OF TICKETS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bay Tek Games TOWER OF TICKETS

Summary of Contents for Bay Tek Games TOWER OF TICKETS

  • Page 2: Factory Contact Information

    FACTORY CONTACT INFORMATION BAY TEK GAMES INC. TOWER OF TICKETS IS AN ELAUT Pulaski Industrial Park GAME, BUILT WITH PERMISSION 1077 East. Glenbrook Drive BY BAY TEK GAMES. Pulaski, WI 54162 USA JOIN OUR SERVICE FIRST NETWORK! This free service is intended to keep you up to date on the latest game information, early notification of parts specials, pertinent technical bulletins, updates on retro fit parts, software upgrades, and much more.

  • Page 3: Table Of Contents

    WELCOME TO: Tower of Tickets ........4...

  • Page 4: Welcome To: Tower Of Tickets

    WELCOME TO: Tower of Tickets Congratulations on your Tower of Tickets purchase! Tickets are king in the gameroom, and Tower of Tickets provides a big draw with it’s visually exciting ticket cones and bright lighting. The four-player unit allows cash to be...

  • Page 5: How To Play

    Choose one of the four brightly-colored player sta- tions. Simply press the button to activate the swinging arm. Time your move just right to push a Tower of Tickets off the rotating platform! Grab your tickets and redeem them for prizes!

  • Page 6: Specifications

    GAME SPECIFICATIONS POWER REQUIREMENTS WEIGHT INPUT VOLTAGE 100 to 120 220 to 240 NET WEIGHT 480 lbs. RANGE SHIP WEIGHT 540 lbs. INPUT FREQUENCY 50 HZ 60 HZ DIMENSIONS RANGE WIDTH 55” MAXIMUM CURRENT DEPTH 55” 5.5 AMPS @ 115 VAC HEIGHT 85”...

  • Page 7: Game Settings

    4 ($1.00) 6 ($1.50) CREDITS PER PLAY DIP 1 DIP 2 *Tower of Tickets is equipped with an anti-cheat tilt bob alarm. Please ensure your staff is familiar with this alarm, and keep it at a high volume to deter cheating.

  • Page 8: Set Up Guide

    QUICK SET UP GUIDE Place the game near its final location. Unlock the dome and open; remove and unpackage the four button boxes. The hardware packet is located in the red station cashbox. Attach the four button boxes to the sides of the cabinet using included washers and lock nuts.
  • Page 9 QUICK SET UP GUIDE Remove the plastic top of the red beacon (found inside the dome) by turning it counter-clockwise. Plug in the beacon cable at the top of the marquee and place the beacon so that the red button is aligned with the cut out area (button should NOT be pressed in).
  • Page 10 QUICK SET UP GUIDE Evenly distribute the ticket tower kit across the mirror. See page 11 for information about the ticket tower rolls. Close the dome and lock. Plug power cord into a standard electrical outlet and turn the power switch on the outlet strip (inside the red station door) to ON.

  • Page 11: Ticket Tower Roll Kits

    Be sure to have your attendants restock the playfield often. To order more Ticket Tower rolls, contact: Bay Tek Games: 920-822-3951 Elaut USA: 732-494-4900 A full Ticket Tower roll kit consists of:...

  • Page 12: Mainboard Pinout & Wiring

    MAINBOARD PINOUT (AACB5150) Marquee Under Glow LEDs Tilt Bob Beacon AACE5171 AACE 5153 AACE5182   AACB5150 To Speaker AACE5175 To Speakers AACE5175 Power Supply AAPS1008-TOT Prize/Alarm Volume Game Volume Comm. to Comm. to Station 4 Station 1 Ribbon Ribbon Comm. to Comm.
  • Page 13 WIRING DIAGRAM: MAINBOARD + MARQUEE POWER Under Glow Beacon Lights AABA0002 AACE5171 Tilt Bob A5TI1001 Under Glow Beacon Cable Cable AACE5182 AACE5171 Tilt Bob Cable   AACE5153 Main Ground Lug Marquee Lights Attached = AACE5168(4) AACE5172 AACE5181(1)   A5CB5150 AACE5170 Marquee Cable  ...
  • Page 14 WIRING DIAGRAM: POWER IN + MARQUEE SPEAKER   Speaker AACE8811 AACE5175 Marquee Speaker Cable A5CB5150   Power Supply Connector   Power Supply AAPS1008-TOT AC Power to Bill Acceptor AACE2316   AC Power to Power Supply A5CORD5 Line Filter A5FI9010      ...

  • Page 15: Door Board Pinout & Wiring

    DOOR BOARD PINOUT (AACB5151) Marquee Ticket/Game Marquee Side Cabinet Arms Counters Arms Lights AACE5177 AACO1000 AACE5161 AACE5173   Arm Motor Home/Away Sensors AACB5172 A5CB5151 MAINBOARD AACB5151  Coin Mech Comm. Ribbon A5CM-AS-COMP Prize Sensors AABD7003 AABD7004 Menu Buttons Upper/Lower Bill Acceptor AAPB7300 Arm Lights &...
  • Page 16 WIRING DIAGRAM: LIGHTS, SENSORS, MOTORS, DBA Marquee Support Arm Arm Motor (X4) Assembly AAMO5150 LED light strip (game sides) AACE5173   Arm Motor Home/Away Sensors AACB5152     Motor Cable       AACE5151     Arm Cable Side Light Arm Cables AACE5164 Cable...
  • Page 17 WIRING DIAGRAM: COUNTERS, COIN MECH, BUTTON Coin Comparator Coin Comparator Set to NC A5CM-AS-COMP Coin Cable Counters AACE1527 AACO1000 Counter Cable AACE5156 TICKETS GAMES A5CB5151 Player Button A5PB7300 Player Button Cable   AACE5155...

  • Page 18: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Troubleshoo ng Strategy Use common sense and a systematic method of troubleshooting to determine the exact problem, probable cause and remedy. Use the process of elimination to find the faulty component. Always check for the simple and obvious causes first such as unplugged, loose or broken wires and bad sensors, bent, pinched, stuck or jammed components.
  • Page 19 TROUBLESHOOTING GUIDE Problem Probable Cause Remedy No Communication Main Board and WIRING TO Power Supply OK. between boards. Check green LED’s on Central Main board. “Power” solid ON   If “Power” is not solid ON If LEDs are not on  ...
  • Page 20 TROUBLESHOOTING GUIDE Problem Probable Cause Remedy Home / Away Sensor under A. Adjust Sensors in and out to stop arm Playfield Arms moving too far in/out playfield is faulty movement. Sensor wiring broken B. Trace wiring from Sensors to Door Board.
  • Page 21 TROUBLESHOOTING GUIDE Problem Probable Cause Remedy A. Trace wiring from the corner of the Marquee Lights are out Ensure Marquee Cable is cabinet to the Power Supply. The power plugged in at the inter- section between the supply is the feed for power on these dome and cabinet, by the lights.

  • Page 22: Bill Acceptor Diagnostics

    BILL ACCEPTOR DIAGNOSTICS Note: There are many different models and brands of Bill Acceptors that are used on redemption games. Your Bill Acceptor may differ from the unit shown. An up-stacker should be used for clearance issues. Standard DBA is MEI # AE2431-D5E Part # A5AC9091 Determine if Bill Acceptor has power: Turn game ON—The bill acceptor should make noise as stacker cycles and green lights on outside bezel should flash.

  • Page 23: How To: Access Circuit Boards

    HOW TO: ACCESS MAIN & DOOR BOARDS Unlock the Red Station access door. Central Main Board (A5CB5150), Power Strip, and Power Supply can be accessed through this station. Each individual station has its own Door Board (A5CB5151) that can be accessed inside each door.

  • Page 24: How To: Access Motors & Cables

    HOW TO: ACCESS MOTORS & CABLES Power off the game before servicing. Unlock the two locks above the red player station and lift the dome until it rests on its hinges. Opening the dome allows access to the playfield, prize sensors, and game arms. Remove the (4) bolts/screws that secure the playfield.

  • Page 25: Decal Identification

    DECAL IDENTIFICATION A5DE5150_TOT_MarqueePanels A5DE5169_TOT_RingGreen A5DE5157_TOT_ArmLtBlue A5DE5178_TOT_ArmRtRed A5DE5179_TOT_RingRed A5DE5159_TOT_RingBlue A5DE5176_TOT_ControlPanelRed A5DE5161_TOT_CabTopGreen A5DE5171_TOT_CabTopRed A5DE5166_TOT_ControlPanelGreen A5DE5172_TOT_CabMidRed A5DE5173_TOT_CabBottomRed A5DE5174_TOT_CashDoorRed A5DE5162_TOT_CabMidGreen A5DE5165_TOT_CabPrizeDoorGreen A5DE5175_TOT_CabPrizeDoorRed A5DE5163_TOT_CabBottomGreen A5DE5160_TOT_CornerPanels A5DE5164_TOT_CashDoorGreen NOT VISIBLE ON PHOTO: A5DE5151_TOT_CabTopBlue A5DE5167_TOT_ArmLtGreen A5DE5185_TOT_CabPrizeDoorYellow A5DE5152_TOT_CabMidBlue A5DE5168_TOT_ArmRtGreen A5DE5186_TOT_ControlPanelYellow A5DE5153_TOT_CabBottomBlue A5DE5177_TOT_ArmLtRed A5DE5187_TOT_ArmLtYellow A5DE5154_TOT_CashDoorBlue A5DE5181_TOT_CabTopYellow A5DE5188_TOT_ArmRtYellow A5DE5155_TOT_CabPrizeDoorBlue A5DE5182_TOT_CabMidYellow A5DE5189_TOT_RingYellow A5DE5156_TOT_ControlPanelBlue A5DE5183_TOT_CabBottomYellow A5DE5158_TOT_ArmRtBlue...

  • Page 26: Maintenance Log

    MAINTENANCE LOG If repairs are necessary, it is good practice to keep a log of repairs done and parts ordered. The chart below will assist you in tracking your game’s maintenance. DATE MAINTENANCE PERFORMED PARTS ORDERED INITIALS...

  • Page 27: Technical Support

    Bay Tek games. Many of our games share the same main-board electronics. This means you can buy one set of spare electronics to support many of your Bay Tek games. Spare boards allow you to get your game up and running the quickest and provide you a valuable troubleshooting option. Call our...

  • Page 28: Warranty

    WARRANTY Bay Tek Games warrants to the original purchaser that all game components will be free of defects in workmanship and materials for a period of 6 months from the date of purchase. If you fill out the registration card in the cashbox of the game, Bay Tek will add another 3 months to your warranty, free of charge.
