Technical Information
Electrohydraulic Actuators PVE-EX
Installation

Mounting of PVG

© Danfoss | October 2017
20 × 1.5 mm
M20 × 1.5 mm
For mounting information regarding PVG products, see Literature reference.

Mounting options and guidelines

The PVE-EX can be installed as either standard mount or optional mount.
Standard assembly
B
PVE-EX
PVP
PVB
kwa1464203083245
A
P → A
7-9 N•m
[61-79 lbf•in]
Q max: P → B
Q max: P
PVM
V310474.A
PVS
→ A
BC00000393en-US0102 | 19
