UDI R/C U64 User Manual page 3

Slider drone parts installation
①
Wings installation
Installation: Distinguish left and right wings,
aim at the body hole to push until end.
Disassembly:
Apply force to pull the wings
out is fine.
②
Drone tail installation
Installation: Firstly connect the drone tail to the drone body hole and then rotate the
drone tail, push the upper buckle of drone tail to the drone body buckle.
Disassembly: Pull out the drone tail buckle and then rotate to disassemble.
③
Slider drone decoration propeller installation
Installation: Make sure the slider drone decoration
propeller to aim at the front buckle and push until end.
Disassembly: Apply force to pull out the decoration
propeller.
④
Slider drone doll and hang lift assembly
Installation: Hang the doll to the lift and then install the hang lift to the arm slot in
the drone bottom.
Disassembly: Pull out one side hook of the hang lift, and then another side to
remove the doll.
①
Left Wing
④
3
Front
②
③
①
Right Wing
Rear
