Malibu - Double Cupboard MK2

Assembly Instructions -

Dimensions

Width - 73.5cm

Depth - 49cm

Height - 72cm

Important -

Please read these instructions fully before starting assembly

If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800

Please keep for future reference

Dimensions

621/3372

621/3389

621/3883

MADE IN

BRITAIN

Issue 2 - 18/03/13

Need help?

Do you have a question about the Malibu Double Cupboard MK2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Malibu Double Cupboard MK2

Page 1 Malibu - Double Cupboard MK2 Assembly Instructions - 621/3372 Please keep for future reference 621/3389 621/3883 Dimensions Dimensions Width - 73.5cm Depth - 49cm MADE IN Height - 72cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 2 - 18/03/13...
Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 23kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (D1161A) (D1387A) (D1170A) (706 x 442mm) (706 x 442mm) (733 x 490mm) Base...
Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the left side Fit 2 hinge plates onto the left side , making sure that the slot is facing towards the finished front edge.
Page 6 Assembly Instructions Step 3 Join the right side and base Position the base against the right side as shown and secure with 2 screws p l a c h i s u r f a c Finished front edge Finished Step 4 front edge Prepare the plinth...
Page 7 Assembly Instructions Step 6 Fit the left side Push the left side onto the assembly as shown and secure with 3 screws Finished front edge Step 7 Prepare the top Screw 4 metal dowels into the top Note: Tighten metal dowels up fully against the panels.
Page 8 Assembly Instructions Step 8 Fit the top Push the top onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the inside of the side panels Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
Page 9 Assembly Instructions Step 10 Fit the shelf Insert 4 shelf studs the required height. Lower the shelf down onto the shelf studs Step 11 Prepare the doors Push fit 2 hinges into each of the doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
Page 10 Assembly Instructions Step 12 IMPORTANT Drill the handle hole Carefully choose which hole you will need to drill in the doors Important: Please follow these instructions carefully. ONLY drill This will be the left door this hole Lay the door down onto a smooth surface.
Page 11 Assembly Instructions Step 13 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 12 C. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR2697...
Page 13 Malibu - Double Cupboard MK2 Assembly Instructions - 621/3372 Please keep for future reference 621/3389 617/3883 Dimensions Width - 73.5cm Depth - 49cm MADE IN Height - 72cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 4 - 04/09/14...
Page 14 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 23kgs. space to layout the parts before recommend the Please lift with care. starting.
Page 15 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side (D2832A) (D2833A) (D2817A) (706 x 444mm) (706 x 444mm) (733 x 490mm) Base...
Page 16 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
Page 17 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the left side Fit 2 hinge plates onto the left side , making sure that the slot is facing towards the finished front edge.
Page 18 Assembly Instructions Step 3 Join the right side and base Position the base against the right side as shown and secure with 2 screws p l a c h i s u r f a c Finished front edge Finished Step 4 front edge Prepare the plinth...
Page 19 Assembly Instructions Step 6 Fit the left side Push the left side onto the assembly as shown and secure with 3 screws Finished front edge Step 7 Prepare the top Screw 4 metal dowels into the top Note: Tighten metal dowels up fully against the panels.
Page 20 Assembly Instructions Step 8 Fit the top and fit the 4 plasinails Push the top onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the inside of the side panels Note: Turn the large locking nuts as far as they will go - more than...
Page 21 Assembly Instructions Step 10 Fit the shelf Insert 4 shelf studs the required height. Lower the shelf down onto the shelf studs Step 11 Prepare the doors Push fit 2 hinges into each of the doors Secure each hinge with 2 screws Note: Before securing with the screws, make...
Page 22 Assembly Instructions Step 12 IMPORTANT Drill the handle hole Carefully choose which hole you will need to drill in the doors Important: Please follow these instructions carefully. ONLY drill This will be the left door this hole Lay the door down onto a smooth surface.
Page 23 Assembly Instructions Step 13 Fit doors and handles Note: The easiest way to attach each door to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
Page 24 C. Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3037...
