Technical Specifications

Model
Electrical
Power
Roller Size (Dia. x W)
Roller Adjustable Gap
Conveyor Belt Width
Conveyor Width
Conveyor Belt Speed
Roller Speed
Maximum Dough Capacity
Maximum Working Position
Dimensions
Resting Position
Dimensions (W x H)
Weight
Item Number

Installation

1. Installation must be performed on a flat, dry surface with a stable temperature environment. Press down
pedals of active wheels to lock the machine.
2. Follow the instructions on the plaque of electrical cabinet to connect power supply. The breaker for power
supply should be installed on the wall with 1.7 m height from the floor.
3. Pull conveyor straight, put down the table and then put down both safety guards.
4. Then check the movement of the conveyors. Press the left-hand side pedal and the conveyors move left.
Press the right-hand side pedal and the conveyors move right. If the movement is in the wrong direction,
change the two wires of the power supply and re-test the machine.
5. The power cord must be grounded.

Operation

1. When using machine, set the thickness handle to the most left position.
2. NOTE: Do not put hands into safety guard.
3. Switch the power off and disconnect from the socket when cleaning.
4. Lift up safety guards after operation and then turn off power switch.
BE-CN-2083-CSS
220 V / 60 Hz / 1
0.5 HP/ 0.37 kW
3.5" x 20.5" / 88 x 520mm
1 - 35mm
19.75" / 502mm
22.5" / 572mm
18m/min - 32m/min
124r/min
11 lbs. / 5 kgs.
35" x 88" x 25.6" / 889 x 2235 x 650mm
25.5" x 36.25" / 648 x 921mm
275.6 lbs. / 125 kgs.
42154
