Kitting - SureCall FusionProfessional User Manual

Kitting

Component Product number
Outdoor Antenna* SC-288W / SC-289W
SC-230W / SC-231W
Outdoor Cable* SC-400 (50')
Inside Cable* SC-240 (20')
Inside Antenna* SC-248W
SC-222W
SC-121W
SC-302W
Frequency Input
(MHz) (dBm)
Uplink: 1710-1755 -43.4
Uplink: 1850-1915 -43.8
Uplink: 824-849 -37.9
Uplink: 698-716 -36.9
Uplink: 777-787 -36.5
Downlink: 2110-2155 -59.4
Downlink: 1930-1995 -60.4
Downlink: 869-894 -50.5
Downlink: 728-746 -50.5
Downlink: 746-757 -51.0
FCC 15.105 Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help.
15.19 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Warning: Any product modifications that use unauthorized antennas, cables, and/or coupling devices are prohibited by the FCC. Contact FCC for details:
1-888-CALL-FCC. Changes or modifications not expressly approved by SureCall could void the user's authority to operate the equipment.
SureCall, Inc | 1-888-365-6283 | support@surecall.com | www.surecall.com
Gain/Loss
LTE-A LTE-V Cellular
707 MHz 731 MHz 800 MHz
3 dBi 3 dBi 3 dBi
7 dBi 7 dBi 8 dBi
3.01 dB 3.01 dB 3.14 dB
2.06 dB 2.06 dB 2.29 dB
7 dBi 7 dBi 7 dBi
3 dBi 3 dBi 3 dBi
1.2 dBi 1.2 dBi 1.2 dBi
2.5 dBi 2.5 dBi 3 dBi
PreAGC
Pulse GSM
Output Gain
(dBm) (dB)
24.4 67.8
25.1 68.9
25.6 63.5
25.4 62.3
25.1 61.6
9.3 68.7
9.5 69.9
11.2 61.7
11.1 61.6
10.2 61.2
PCS AWS
1900 MHz 1700 / 2100 MHz
4 dBi 4 dBi / 4 dBi
10 dBi 10 dBi / 10 dBi
4.31 dB 4.07 dB / 4.56 dB
3.56 dB 3.36 dB / 3.76 dB
10 dBi 10 dBi / 10 dBi
6 dBi 6 dBi / 6 dBi
3 dBi 3 dBi / 3 dBi
5 dBi 4 dBi / 5 dBi
4.1 MHz AWGN
Input Output
(dBm) (dBm)
-47.1 20.7
-47.0 21.0
-38.5 24.5
-37.1 23.8
-36.3 25.2
-60.4 8.0
-61.7 8.0
-51.6 9.9
-52.2 8.8
-52.3 8.1
Kitting
Note
50 Feet or longer
20 Feet or longer
Gain
(dB)
67.8
68.0
63.0
60.9
61.5
68.4
69.7
61.5
61.0
60.4
13
